Kinetec CEM - Transporting the Device; Description

KINETEC CEM™ 6/22 EN
4
3
9
8
10
9
11
13
12
DESCRIPTION
11. Transporting the device
For easy transport of the unit, the chair has two wheels (3) and a handle
(4).
Place the arm support as close as possible to the chair to limit the overall
dimensions and help balance the unit.
Place your foot as indicated to tilt the unit.
You can adjust the height of the handle with the knobs (9).
12. Description
The device KINETEC CEM™ consists of the following
components:
1 – Chair
2 – Base
3 – Wheels
4 – Handle
5 – Arm rest knobs
6 – Arm rest
7 – Hand control support
8 – Right/left sliding motor mount bar locking knob
9 – Up/down sliding housing locking knob
10 – Chair locking knob
11 – Abduction motor locking knob
12 – Abduction motor
13 – Shoulder depth sliding lock
1
2
3
4
5
6
7
