KINETEC CEM™
20/22
EN
PRODUCT INFORMATION
5. Technical specifications
Product:
Lifespan of the machine: 12 years
Weight: Complete KINETEC CEM™: 28 Kg (61.7 pounds),
KINETEC™ CEM module: 4.6 Kg (10 pounds)
Splint dimensions: Complete KINETEC CEM™: 56cm (22 ins.) x 100cm (39 ins.) x 76cm (30 ins.),
KINETEC CEM™ module: 20cm (7.8 ins.) x 18cm (7 ins.) x 62cm (24.4 ins.)
Angular limits: -10° to 135°
Speeds: from 50 to 145° per minute
Patient sizes: 1.40m (4ft. 7ins.) to 2m (6ft. 7ins.)
Maximum weight of the user: 135 kg (297 pounds)
Acoustic pressure: <70dB
Electricity:
Power supply: 100-240V~
Frequency: 50-60 Hz
Power consumption: 50 VA
Class: Device of Type BF Class II or Type B Class I
Protection classification: IP 20
(Protected against solid objects greater than 12.5mm, but not protected against liquids)
Fuse: T 750mA 250V 6.3 x 32mm (KINETEC
©
order: 4610007434)
Environment:
Storage/transport conditions: Temperature: -25 to 70°C / -13 to 158°F.
Relative humidity: up to 93% without condensation.
Operating conditions: Temperature: 5 to 40°C / 41 to 104°F.
Relative humidity: 15% to 93% without condensation.
Atmospheric pressure: 700 hPa to 1060 hPa.
6. Symbols used
Consult the accompanying documentation
or Operational warning
Speed
Shoulder positioning
STOP (power off)
Timer
Warm up
ON (power on)
Force
Modulation
Start movement
Pause
ByPass
Stop movement
Increase
Session time
Program access
Decrease
Follow the instructions for use
Contains electric and electronic
components; not to throw in the dustbins
of household refuse
Extension limit
~
Keep dry during storage or transport
Flexion limit
Right way up when box is stored
Follow the instructions for use
Temperature Limit during storage or
transport
Fragile
Hand control unlocked
Do not push
Hand control locked
Class II device
Hand control half locked
Fault or power-on indicator
TYPE BF device
(protection against electric shocks)
TYPE B device
(protection against
electric shocks
)
7. Warranty
The KINETEC
®
warranty is strictly limited to the replacement, free of charge, or to factory repairs of part(s) recognised as defective.
Kinetec SAS guarantees its continuous passive motion systems for 2 years against all defects of manufacture from the date of purchase by the consumer.
Kinetec SAS is the only organization able to assess the application of the warranty to its systems.
The warranty will be considered null and void if the device has been used abnormally or under conditions of use other than those indicated in the user's
manual.
The warranty will also be considered null and void in the event of deterioration or an accident due to negligence, inappropriate surveillance or inappropriate
maintenance, or due to transformation of the equipment or an attempt to repair the equipment.
