Essential Series Gold and Platinum
6
III. System Data Sheets
Essential Gold
Design Specifications
Flow Rate @ 15 psid 9.5 gpm 36 Lpm
Pressure Range 25 - 125 psi 1.7 - 8.6 bar
Temperature Range 35˚- 120˚F 2˚- 50˚C
Free Chlorine ≤1.0 mg/L ≤1.0 mg/L
Compensated Hardness ≤42 gpg ≤684 mg/L
Iron (ferrous) <0.5 mg/L <0.5 mg/L
Iron (ferric) <0.01 mg/L <0.01 mg/L
System Components
Media Vessel (Qty. 1) 8" x 17" 203 mm x 432 mm
Media Vessel Construction Fiberglass Wrapped Polyethylene
Empty Bed Volume 0.37 cubic feet 10.5 liters
Media Type Fine Mesh Cation Resin
Media Volume (per tank) 0.37 cubic feet 10.5 liters
Total Bed Depth 17" 432 mm
Free Board None
Riser Tube 1.05" ABS 27 mm ABS
Distributor Upper 0.007" Slots, Cone Type 0.18 mm Slots, Cone Type
Distributor Lower 0.007" Slots, Cone Type 0.18 mm Slots, Cone Type
Regeneration Control Volumetric
Service Flow Upflow
Regeneration Flow Downflow
Regeneration Type Countercurrent
Hard Water By-pass During Regeneration Automatic
Salt Capacity (Pellet) 60 lb 27.2 kg
System By-pass Optional
Connections
Inlet / Outlet Connections Custom Adapter and Bracket
Drain Connection 0.5" Quick Connect Tubing
Brine Line Connection 0.375" Quick Connect Tubing
Brine Tank Overflow 0.625" Tubing Barb
Power None
System Part Number
Essential Gold 15759
Dimensions and Weight
Height 24" 610 mm
Width 12" 305 mm
Depth 18" 457 mm
Shipping Weight 50 lb 22.7 kg
Operating Weight 130 lb 59.0 kg
Regeneration Specifications at 35 psi
Oine Time During Regeneration Cycle 13.5 minutes
Total Regeneration Cycle Time 15 minutes
Total Regeneration Volume 6.6 gallons 25 liters
Salt Used per Regeneration 0.8 lb 0.36 kg
Salt Dose 2.1 lb / cu ft3 33.7 grams NaCl/liter resin
System Capacity 3,660 grains 237 grams
Backwash Flow Rate 1.0 gpm 3.78 Lpm
18” / 457 mm
12” / 305 mm24” / 610 mm
