Chapter 1 Before Use 1-7
1. 4. 3 Scanner part
Subject Specification
Scanning method Contact Image Sensor (CIS)
(5 pieces of A4 sized CIS)
Light source LED (R/G/B)
Setting of original Face up
Starting point of scan Center
Scan width Max: 36” or 914.4mm
Min : 279.4mm
Scan length Max: 19.7ft or 6,000mm (Including the margin area)
Min : 8.5” or 210mm (Including the margin area)
Margin area 3mm from leading, trailing and both side edges
Optical resolution 600dpi
Digital resolution 200 / 300 / 400 / 600 dpi
Original transportation Sheet through type
Transportable original
thickness
Max: 1.60mm
Min : 0.05mm
Scanning speed 65 mm per second
NOTE
The above specifications are subject to change without notice.
NOTE
If the original is thicker than 0.6mm, its image quality is not
guaranteed.
To Next Page
