Chapter 2 Basic Operation 2-9
8. Hold the green grip (12: on the middle of Guide Plate) and turn Guide Plate outside.
With holding, rotate Feed Knob (10) again so that the leading edge comes out in 100mm.
9. Slide the green Cutter Knob (13) fully from one side to the other to make a new straight edge.
Remove the cut portion.
10. Close Roll Deck.
NOTE
Completely slide Cutter Knob (13) until it stops at either end.
Not doing so may cause a paper jam.
Correct Wrong
NOTE
Be sure to close the Roll Deck fully until it locks at the correct position.
A paper jam may occur if it is not locked firmly.
Leading edge 12
10
13
1313
To Next Page
