KIP 660 - Page 67

Chapter 3 Error Correction 3-18
5. Press and hold the Lever (9) downward and then fully move (pivot) the entire Feeder Unit (10)
toward the printer’s front. Take out a remaining (portion of) sheet.
6. Return the Feeder Unit (10), the Left Side Cover (3) and the Fuser Cover (2) in position.
9
3
2
10
10
