KIP 770K - Roll Deck Section Jam (Deck 1 Mis-Feed)

Chapter 3 Error Correction 3-3
3. 1. 1 Roll Deck Section Jam (Deck 1 Mis-feed)
1. Open the Roll Deck Cover.
Rewind the roll onto the media core.
2. Rotate the roll media in the arrow direction and insert the leading edge of the roll media to the
media path until it touches the feeding rollers (1).
After that, the leading edge will automatically go into the roll media’s wait position.
3. Close the Roll Deck Cover.
Roll Deck Section
- Deck 1 Mis-feed
1
