Chapter 3 Error Correction 3-8
3. 1. 4 Fuser Section Jam (Separation Mis-feed)
1. Hold the blue handle (1) and open the Fuser Cover (2).
2. If it is possible, pull and remove the mis-feed media.
If little amount of the leading edge area is coming to the Fuser and you cannot pull it out,
or if the trailing edge remains deep to be caught in the printer, do not pull it by force.
Leave it there and go to the next step.
WARNING
There are extremely hot parts inside the Fuser Unit. Do not touch any parts in the Fuser Unit,
or you will be burnt.
Also the mis-fed media can be very hot. Be careful not to get burnt when you remove it.
2
1
2
Fuser Section
- Separation Mis-feed
To Next Page
