2CC1-10-X7R500-10
2K
Multi-layer chip capacitor
MURATA,GRM155R71H102K
A01D,1,nF,±
10%,50V,0402,X7R
14
C120,C124,C526,C536,C573,C581,C31,C93,C94,
C95,C96,C98,C613,C614
47
2CC1-10-X7R500-10
3K
Multi-layer chip capacitor
MURATA,GRM155R71H103K
A88D,10,nF,±
10%,50V,0402,X7R
18
C61,C110,C112,C115,C12,C17,C57,C58,C326,C3
27,C328,C329,C529,C539,C540,C42,C49,C612
48
2CC1-10-X7R500-15
3K
Multi-layer chip capacitor
MURATA,GRM155R71H153K
A12D,15,nF,±
10%,50V,0402,X7R
2
C547,C545
49
2CC1-10-X7R500-27
1K
Multi-layer chip capacitor
MURATA,GRM155R71H271K
A01D,270,pF,±
10%,50V,0402,X7R
1
C36
50
2CC1-10-X7R500-47
1K
Multi-layer chip capacitor
murata,GRM155R71H471KA0
1D,470,pF,±
10%,50V,1005,X7R
51
C55,C102,C104,C113,C118,C122,C14,C7,C8,C9,
C10,C11,C64,C65,C66,C67,C230,C231,C232,C23
3,C237,C238,C239,C240,C241,C242,C243,C332,
C107,C519,C522,C523,C528,C530,C531,C532,C
533,C535,C537,C538,C541,C549,C550,C551,C5
53,C554,C559,C564,C565,C21,C333
51
2CC1-10-X7R500-47
2K
Multi-layer chip capacitor
MURATA,GRM155R71H472K
A01D,4.7,nF,±
10%,50V,0402,X7R
1
C527
52
2CC1-10-Y5V160-10
5Z
Multi-layer chip capacitor
murata,GRM155R61C105KA1
2D,1,uF,+80%/-20%,16V,1005,
Y5V
9
C38,C134,C136,C137,C138,C139,C140,C141,C1
42
53
2CC1-16-C0G500-10
2J
Multi-layer chip capacitor
murata,GRM1885C1H102JA0
1D,1000,pF,±
5%,50V,1608,C0G
2
C52,C97
54
2CC1-16-C0G500-12
0J
Multi-layer chip capacitor
murata,GRM1885C1H120JA0
1D,12,pF,±5%,50V,1608,C0G
1
C507
