Page #43 background imageLoading...
Page #43 background image
DP485 Service Manual
40
88
2RS1-10-100J
Chip resistor
yageo,RC0402JR-0710RL,10,
Ω,±5%,0402
3
R66,R244,R559
89
2RS1-10-101J
Chip resistor
yageo,RC0402JR-07100RL,10
0,Ω,±5%,0402
1
R36
90
2RS1-10-102J
Chip resistor
yageo,RC0402JR-071KL,1K
Ω,±5%,0402
19
R108,R3,R50,R60,R236,R237,R238,R239,R6,R1
0,R502,R539,R544,R545,R547,R551,R560,R623,
R340
91
2RS1-10-103J
Chip resistor
yageo,RC0402JR-0710KL,10,
KΩ,±5%,0402
19
R103,R110,R1,R48,R52,R53,R55,R57,R58,R59,R
68,R70,R245,R601,R614,R172,R173,C611,R86
92
2RS1-10-104J
Chip resistor
yageo,RC0402JR-07100KL,10
0,KΩ,±5%,0402
1
R63
93
2RS1-10-105J
Chip resistor
yageo,RC0402JR-071ML,1,M
Ω,±5%,0402
1
C59
94
2RS1-10-152J
Chip resistor
yageo,RC0402JR-071K5L,1.5,
KΩ,±5%,0402
2
R507,R51
95
2RS1-10-153J
Chip resistor
yageo,RC0402JR-0715KL,15,
KΩ,±5%,0402
2
R512,R542
96
2RS1-10-155J
Chip resistor
yageo,RC0402JR-071M5L,1.5,
MΩ,±5%,0402
1
C109
97
2RS1-10-182J
Chip resistor
yageo,RC0402JR-071K8L,1.8,
KΩ,±5%,0402
1
R618
98
2RS1-10-203J
Chip resistor
yageo,RC0402JR-0720KL,20,
KΩ,±5%,0402
1
R529
99
2RS1-10-220J
Chip resistor
yageo,RC0402JR-0722RL,22,
Ω,±5%,0402
1
R511
100
2RS1-10-221J
Chip resistor
yageo,RC0402JR-07220RL,22
0,Ω,±5%,0402
2
R249,R250
101
2RS1-10-222J
Chip resistor
yageo,RC0402JR-072K2L,2.2,
KΩ,±5%,0402
3
R102,R246,R247
102
2RS1-10-223J
Chip resistor
yageo,RC0402JR-0722KL,22,
KΩ,±5%,0402
2
R27,C34
