DP580 Service Manual
3
-10-X7R100-224
R multi-layer chip capacitor
220nF±10%, 10V, X7R
C3,C8,C12,C31,C332,C352
4
-10-X5R100-474
R multi-layer chip capacitor
470nF±10%, 10V, X5R
C4,C9,C13,C18,C19,C22,C28,C33,C34,C36,C37,C38,C40,C
41,C45,C52,C308,C528,C529,C531,C532,C534,C536,C87,C
90,C162,C53,C54,C55,C56
5
-32-X5R160-226
SMD multi-layer chip
capacitor
22μF±10%, 16V,
X5R, Torch
C16,C17,C23
6
-10-X7R500-103
R multi-layer chip capacitor
10nF±10%, 50V, X7R
C21,C178,C183,C188,C195,C197,C218,C220,C225,C232,C2
33,C238,C253,C293,C326,C327,C328,C329,C331,C356,C35
7,C224
7
-10-X7R160-104
R multi-layer chip capacitor
100nF±10%, 16V, X7R
C24,C48,C73,C91,C92,C95,C96,C103,C104,C110,C111,C12
6,C128,C139,C141,C143,C152,C155,C156,C158,C159,C161,
C234,C244,C249,C260,C264,C281,C283,C294,C296,C298,C
475,C333,C334,C340,C346,C349,C359,C437,C63,C64
,C423,
C424,C425,C426,C427,C428,C439,C440,C441,C172,C499,C
505,C506,C507,C42,C518,C519,C182,C177,C443,C455,C45
6,C544,C545,C433,C435,C450,C453,C454,C457,C458,C461,
C386,C387,C436,C451,C478,C479,C485,C491,C492,C498
8
-20-Y5V160-106
Multi-layer chip capacitor
10uF+80%/-20%, 16V,
C32,C35,C39,C307,C393,C398,C403,C404,C448,C527,C530
,C533,C535,C47,C85,C88,C149,C236,C237,C338,C348,C44,
C46,C50,C370,C371,C373,C374,C376,C377,C381,C382,C39
1,C399,C60,C418,C421,C444,C445
9
-NSR1020MW2
SMD Schottky barrier
D1,D23
