DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
21
2RS1
-10-103J R chip resistor
1005,
10K±5%
46
R1,R28,R32,R35,R39,R50,R51,R214,R109,R229,R175,R176
,R177,R178,R7,R9,R10,R11,R291,R292,R293,R294,R192,R1
95,R269,R298,R197,R200,R203,R204,R205,R206,R210,R23
0,R242,R243,R244,R245,R265,R266,R224,R267,R268,R277,
R278,R279
22
2RE1-10-6802
Precise SMD resistor
1005, 68K±1%
1
R3
23
2RE1
-10-1602 Precise SMD resistor
1005,
16.2K±1%
1
R4
24
2RS1
-10-102J R chip resistor
1005,
1K±5%
12
R5,R6,R8,R147,R258,R97,R144,R127,R128,R182,R199,R20
1
25
2RS1
-10-334J R chip resistor
1005,
330K±5%
1
R145
26
2RS1
-10-104J R chip resistor
1005,
100K±5%
15
R94,R146,R155,R262,R264,R57,R58,R59,R106,R107,R115,
R116,R307,R29,R228
27
2RS1
-10-471J R chip resistor
1005,
470Ω±5%
7
R306,R154,R261,R263,R259,R260,R231
28
2CC1
-10-C0G500-2R
5B
R multi-layer chip capacitor
1005,
2.5P±0.1P, 50V, C0G
3
C69,C70,C71
29
2CC1
-10-C0G500-2R
0B
Multi-layer chip capacitor
1005,
2P±0.1P, 50V, C0G
4
C72,C119,C134,C173
30
2CC1
-10-C0G500-10
1J
R multi-layer chip capacitor
1005,
100P±5%, 50V, C0G
25
C335,C336,C86,C89,C116,C123,C131,C138,C380,C341,C34
2,C343,C344,C345,C347,C353,C354,C394,C395,C397,C400,
C429,C430,C324,C325
31
2CC1
-10-C0G500-10
0D
R multi-layer chip capacitor
1005,
10P±0.5P, 50V, C0G
11
C242,C120,C121,C122,C135,C136,C137,C144,C167,C171,C
290
32
2CC1
-10-C0G500-6R
8C
Multi-layer chip capacitor
1005,
6.8P±10%, 50V, C0G
1
C302
33
2CC1
-10-C0G500-13
0J
R multi-layer chip capacitor
1005,
13P±5%, 50V, C0G
1
C268
