Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
187
7PLJ
-025006-T01A
High-
temperature barcode
sticker
For SEPURA DMR device
,
supplier: Xiamen Kangyang
brand
1.05
188
1IS1
-LTJIAMI Encryption chip
LTJIAMI,
for radio DP585
1
IC18
189
2CT1
-TP20-100-2R2
M
R SMD Tantalum capacitor
2012,
2.2μF±20%, 10V, TP
series
(Encapsulation P)
1
C402
190
7MDC
-4207-01A-W
VCO shield cover (for radio
DP586)
Copper-Nickel-Zinc alloy, 0.2 mm
thick, square, 31.05*13.3*3,
Chuanghong brand, lead free
1
P1
191
7MDC
-4207-02A-W
GPS shield cover (for radio
DP586)
Copper
-Nickel-
Zinc alloy, 0.2 mm
thick, heteromorphic,
33*13.05*3, Chuanghong
brand,
lead free
1
P2
192
7MDC
-4207-03A-W
Automatic power control
(APC) shield cover (for
radio DP586)
Copper
-Nickel-
Zinc alloy, 0.2 mm
thick, square, 21.3*11.45*2.2,
Chuanghong
brand, lead free
1
P3
193
7MDC
-4207-04A-W
Power shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2 mm
thick, square, 16.2*15.1*2.3,
Chuanghong brand, lead free
2
P4,P5
194
7MDC
-4207-05A-W
Amplifier shield cover (for
radio DP586)
Copper
-Nickel-
Zinc alloy, 0.2 mm
thick, square, 16.3*10.95*2,
Chuanghong
brand, lead free
1
P6
195
7MDC
-4207-06A-W
Baseband shield cover (for
radio DP586)
Copper
-Nickel-Zinc
alloy, 0.2 mm
thick, heteromorphic,
44*19.97*2.3, Chuanghong
brand
, lead free
1
P7
