Kirisun DP990 Service Manual

DP990/DP995service manual
28
11
2CC1-20-X5R160-10
6KD
Multi-layer chip
capacitor
PCS
C112,C117,C118,C625,C1005,C1
019,C1046,C1298,C1414,C157,C1
58,C159,C178,C1299
14
12
2CC1-06-NP0500-1
R0
Precision multi-layer
chip capacitor
PCS
C119
1
13
112C03000022
Ceramic capacitor
PCS
C120
1
14
112C03000023
Ceramic capacitor
PCS
C121
1
15
2CC1-06-C0G250-5
R0C
SMD capacitor
PCS
C122,C1204
2
16
2CC1-06-NP0500-10
0
Multi-layer chip
capacitor
PCS
C123,C132,C148,C302,C626,C80
6,C809,C904,C1066
9
17
112C03000024
Ceramic capacitor
PCS
C124
1
18
2CC1-06-NP0500-56
0
Multi-layer chip
capacitor
PCS
C125
1
19
112C03000009
Ceramic capacitor
PCS
C127
1
20
2CC1-06-X7R500-10
3K
SMD capacitor
PCS
R54,C1120,C129,C802,C1028,C1
032,C1073,C1200,C1202,C1205,C
1206,C1209,C1213,C1222,C1231,
C1234,C1256,C1258,C1259,C126
0,C1261,C1265,C1266,C1267,C12
70,C1274,C1277,C1290,C1291,C1
302,C1304,C1402,C1404,C1429,C
1434,C1462
36
21
2CC1-10-X5R100-10
6
Multi-layer chip
capacitor
PCS
C1121,C1122,C160,C162,C600,C
617,C632,C912,C915,C917,C909,
C923,C1000,C1006,C1018,C1027,
C1255,C1257,C1089,C1282,C128
3
21
22
2CC1-06-C0G500-47
0J
SMD capacitor
PCS
C142,C612,C1224
3
23
2CC1-06-X7R160-10
3
Multi-layer chip
capacitor
PCS
C144
1
24
2CC1-06-X5R6R3-2
25M
SMD capacitor
PCS
C155,C921,C922,C924,C925,C93
0,C1047
7
25
2CC1-10-X7R160-10
4K
Multi-layer chip
capacitor
PCS
C631,C636,C1024,C1062
4
26
2RS1-10-330J
Chip resistor
PCS
R645,R1416
2
27
2CC1-06-C0G500-22
0J
SMD capacitor
PCS
C834,C1034,C1076
3
28
2CC1-10-C0G500-2
R5C
Multi-layer chip
capacitor
PCS
C900,C903,C1448,C1437,C1439,
C1243
6
29
2CC1-10-C0G500-1
R5C
Multi-layer chip
capacitor
PCS
C902,C1017,C1036,C1065,C1438
5
30
2RS1-06-000O
SMD resistor
PCS
R100,R705,C906,R135,R216,R21
7,R438,R628,R903,R907,R908,R9
16,R1003,R1046,R1053,R1056,R1
060,R1065,R1235,R1255,R240,R9
09,R1002,R1018,R243
25
31
2CC1-10-C0G500-47
0J
Multi-layer chip
capacitor
PCS
C907,C1230,C1301
3
32
2CC1-06-X5R6R3-4
74K
SMD capacitor
PCS
C1103,C327,C328
3
33
2CC1-10-C0G500-4
R7C
Multi-layer chip
capacitor
PCS
C1001,C1254
2
