Kirisun DP990 Service Manual

DP990/DP995service manual
33
01
transistor (for
portable digital and
analog radios)
137
1TF1-RD07MUS2B-
501
ER SMD field effect
transistor
PCS
Q1407
1
138
2RE1-06-1003
Precision resistor
PCS
R607
1
139
2RS1-10-474J
Chip resistor
PCS
R101
1
140
2RS1-10-103J
Chip resistor
PCS
R102,R110,R208,R209,R202,R20
3,R1220,R1439
8
141
2RS1-06-470J
Chip resistor
PCS
R103
1
142
2RE1-10-1003
Precise SMD resistor
PCS
R104,R1422,R1430,R108
4
143
2RE1-10-1802
Precise SMD resistor
PCS
R105,R1437
2
144
2RS1-10-000O
Chip resistor
PCS
R1222,R107,R144,R145,R807,R8
13,R915,R1216,R1432,R138,R140
,R147
12
145
2RS1-10-204J
Chip resistor
PCS
R109,R633
2
146
2RE1-10-4991
Precise SMD resistor
PCS
R111
1
147
2RS1-06-330J
SMD resistor
PCS
R918,R919,R113,R218,R219,R23
2,R233,R234,R235,R236,R238,R2
39,R241,R418,R420,R422,R428,R
429,R430,R431,R432,R433,R435,
R437,R441,R442,R606,R653,R65
4,R655,R808,R809
32
148
2RS1-06-472J
SMD resistor
PCS
R114,R115,R610,R612,R614,R10
38,C199
7
149
2RS1-06-220J
SMD resistor
PCS
R204,R205,R206,R207,R212,R21
3,R220,R221,R222,R223,R224,R8
05,R417,R155
14
150
2RE1-06-1202
Precise SMD resistor
PCS
R237,R242,R900,R901
4
151
2RE1-10-49R9-D
Precise SMD resistor
PCS
R302
1
152
2RE1-06-4702
Precise SMD resistor
PCS
R500,R501,R504,R506,R507,R60
1,R615,R1070,R129
9
153
2RE1-06-2003
Precise SMD resistor
PCS
R600
1
154
2RE1-06-2002
Precise SMD resistor
PCS
R1448,R1064,R1209,R1232
4
155
112R01000008
Chip resistor
PCS
R611,R613,R624
3
156
2RS1-10-102J
Chip resistor
PCS
R636,R1237,R1404,R1436
4
157
2RS1-06-104J
SMD resistor
PCS
R631,R642,R643,R646,R802,R81
0,R811,R1059,R1062,R1067,R122
6,R1227,R1228,R1229,R1245,R36
7
16
158
2RS1-06-102J
SMD resistor
PCS
R623,R632,R638,R639,R647,R64
8,R1073,R1236,R1249,R1400,R10
71,R1460
12
159
2RS1-10-150J
Chip resistor
PCS
R637
1
160
2RS1-10-100J
Chip resistor
PCS
R910,R1001,R1005,R1006,R1032,
R1034,R1035,R1055,R1066,R120
1
10
161
2RE1-06-1002
Precise SMD resistor
PCS
R904,R1008,R1009,R1011,R1036,
R1037,R1040,R1061,R1063
9
162
2RS1-10-202J
Chip resistor
PCS
R1004,R1230
2
163
2RS1-16-100J
Chip resistor
PCS
R1007,R1023,R1240,R1246,R110
5
