Kirisun DP990 Service Manual

DP990/DP995service manual
38
C1275,C1279,C1288,C1289,C12
95,C1297,C1303,C1305,C916,C9
18,C100,C114,C628,C115,C113,
C833
6
2CC1-06-C0G500-101J
SMD capacitor
PCS
C102,C126,C131,C135,C140,C14
3,C151,C156,C301,C305,C314,C
323,C501,C502,C504,C505,C507
,C508,C510,C601,C605,C609,C6
23,C627,C805,C807,C810,C812,
C813,C814,C815,C816,C817,C81
8,C819,C820,C821,C822,C919,C
511,C905,C1029,C1043,C1083,C
1115,C1280,C1281,C1284,C1285
,C1286,C1292,C1293,C1294,C12
96,C1300
55
7
2CC1-06-NP0500-330
Multi-layer chip capacitor
PCS
C106
1
8
112C03000026
Ceramic capacitor
PCS
C107,C634,C635,C1104,C1264,C
1417,C1427,C1432
8
9
2CC1-20-X7R500-226M
Multi-layer chip capacitor
PCS
C108,C169,C137,C138
4
10
2CC1-06-X7R500-102K
SMD capacitor
PCS
C111,C128,C152,C200,C618,C61
9,C803,C804,C808,C1105,C400,
C800
12
11
2CC1-20-X5R160-106K
D
Multi-layer chip capacitor
PCS
C112,C159,C178,C117,C118,C15
7,C158,C625,C1005,C1019,C104
6,C1298,C1414,C1299
14
12
2CC1-06-NP0500-1R0
Precision multi-layer chip
capacitor
PCS
C119
1
13
112C03000022
Ceramic capacitor
PCS
C120
1
14
112C03000023
Ceramic capacitor
PCS
C121
1
15
2CC1-06-C0G250-5R0C
SMD capacitor
PCS
C122,C1204
2
16
2CC1-06-NP0500-100
Multi-layer chip capacitor
PCS
C123,C132,C148,C302,C626,C80
6,C809,C904,C1066
9
17
112C03000024
Ceramic capacitor
PCS
C124
1
18
2CC1-06-NP0500-560
Multi-layer chip capacitor
PCS
C125
1
19
112C03000009
Ceramic capacitor
PCS
C127
1
20
2CC1-06-X7R500-103K
SMD capacitor
PCS
C129,C802,C144,C1028,C1073,C
1120,C1200,C1202,C1205,C1206
,C1209,C1213,C1222,C1231,C12
34,C1256,C1258,C1259,C1260,C
1261,C1265,C1266,C1267,C1270
,C1274,C1277,C1290,C1291,C13
02,C1304,C1402,C1404,C1429,C
1434,C1462,R54
36
21
2CC1-10-X5R100-106
Multi-layer chip capacitor
PCS
C160,C162,C1000,C1006,C1018,
C1027,C1255,C1257,C600,C617,
C912,C915,C917,C632,C909,C92
3,C1089,C1121,C1122,C1282,C1
283
21
22
2CC1-06-C0G500-470J
SMD capacitor
PCS
C142,C612,C1224
3
23
2CC1-06-X5R6R3-225M
SMD capacitor
PCS
C155,C921,C922,C924,C925,C93
0,C1047
7
24
112C03000018
Ceramic capacitor
PCS
C620,C621,C1278
3
25
2CC1-10-X7R160-104K
Multi-layer chip capacitor
PCS
C631,C636,C1062
3
26
2CC1-06-X7R500-333K
SMD capacitor
PCS
C645,C646,C163
3
