Kirisun DP990 Service Manual

DP990/DP995service manual
44
199
2RS1-16-271J
Chip resistor
PCS
R1441
1
200
2RS1-10-473J
Chip resistor
PCS
R1442
1
201
2RS1-10-823J
Chip resistor
PCS
R1444
1
202
2RS1-16-103J
Chip resistor
PCS
R1447,R119
2
203
2RT1-NTH5G16P40B33
3J
SMD thermistor
PCS
R1449
1
204
1IS1-TPS65023
Power management chip
PCS
U100
1
205
1IS1-AM1805AQ
RTC IC
PCS
U101
1
206
1IS1-MC74VHC1GT66
High-speed CMOS analog
switch IC
PCS
U110
1
207
125O03000002
Temperature compensated
crystal oscillator
PCS
U201
1
208
1IP1-OMAPL138EZCEA
3
Dual-core CPU
PCS
U401
1
209
1IM1-IS43D16640C-25I
DDR memory
PCS
U500
1
210
1IS1-TLV320AIC14K
CODEC chip
PCS
U601
1
211
1IS1-LM4951ASD
Audio amplifier
PCS
U603
1
212
121I04000002
General-purpose linear IC
PCS
U604
1
213
1IS1-TS3A24159YZPR
Dual-SPDT analog switch
PCS
U800
1
214
1IS1-AT2659
Low-noise amplifier
pcs
U900
1
215
1IS1-RP114K331D-TRB
LDO regulator
PCS
U901,U1101,U1200
3
216
1IS1-XC6204B332MR
SMD voltage regulator IC
PCS
U902,U1002
2
217
121I05000092
SMT IC
PCS
U903
1
218
121I05000024
SMT IC
PCS
U904
1
219
1IS1-XC6204B502MR
SMD voltage regulator IC
PCS
U1000,U1004,U1202
3
220
1TC1-UMC4
SMD Darlington transistor
PCS
U1001,U1006,U1400
3
221
1IS1-SKY72310-11
SMT IC
PCS
U1007
1
222
5OT1-12R8-HHL-0303
Voltage controlled
temperature compensated
crystal oscillator
PCS
U1008
1
223
1IS1-MS5614
D/A converter IC
PCS
U1009
1
224
1IS1-AD9864
Digital IF(intermediate
frequency) system
PCS
U1201
1
225
1IL1-NJM2904V
SMD linear IC
PCS
U1401
1
226
5XC1-32R8-FC-135
SMD crystal oscillator
PCS
X100,Y900
2
227
5OT1-26R0-DSB221SD
N
SMD temperature
compensated crystal
oscillator
PCS
X900
1
228
136P04000074
Multi-layer PCB
PCS
1
229
61SL000008
Burning software
PCS
1
230
9FSO0000165
Burning software
PCS
1
231
1IM1-TC58BVG0S3HB
AI4
Storage IC
PCS
U501
1
232
7MHP-4002-01C-W
TD7700 battery connector
(high shrapnel)
PCS
J100
1
233
7MDC-4182-01A-W
Front shield cover S1 of
mainboard
PCS
P1
1
