Kirisun DP990 Service Manual

DP990/DP995service manual
64
224
1IS1-LM4951ASD
Audio amplifier
PCS
U603
1
225
121I04000002
General-purpose
linear IC
PCS
U604
1
226
1IS1-TS3A24159YZPR
Dual-SPDT analog
switch
PCS
U800
1
227
1IS1-AT2659
Low-noise amplifier
pcs
U900
1
228
1IS1-XC6204B332MR
SMD voltage
regulator IC
PCS
U902,U1002
2
229
121I05000080
SMT IC
PCS
U903
1
230
121I05000024
SMT IC
PCS
U904
1
231
1IS1-XC6204B502MR
SMD voltage
regulator IC
PCS
U1000,U1004,U1202
3
232
1TC1-UMC4
SMD Darlington
transistor
PCS
U1001,U1006,U2300,U1010,
U1011
5
233
1IS1-SKY72310-11
SMT IC
PCS
U1003,U1007
2
234
5OT1-12R8-ADL4-3225
Temperature
compensated crystal
oscillator, for VHF
band (ENE3731A)
PCS
U1008
1
235
1IS1-MS5614
D/A converter IC
PCS
U1009
1
236
1IS1-AD9864
Digital
IF(intermediate
frequency) system
PCS
U1201
1
237
1IL1-NJM2904V
SMD linear IC
PCS
U2301
1
238
125O01000006
SMD crystal
resonator
PCS
X100,Y900
2
239
125O02000001
Voltage controlled
crystal oscillator
PCS
X900
1
240
1IS1-ADE1L
SMD passive
variable-frequency
drive
PCS
Z2400
1
241
5FC1-DSF753SDF-0705
SMD crystal filter
PCS
Z2401
1
242
3CB1-0555600607
Board-to-board
connector (male)
PCS
J801
1
243
7MHP-4002-01C-W
TD7700 battery
connector (high
shrapnel)
PCS
J100
1
244
7MDC-4182-01A-W
Front shield cover S1
of mainboard
PCS
P1
1
245
7MDC-4127-03A-W
Rear-side shield cover
of duplexer board 1
PCS
P3,P5
2
246
7MDC-4127-04A-W
Rear-side shield cover
of duplexer board 2
PCS
P4
1
247
7MDC-4182-04A-W
Front shield cover S4
of mainboard
PCS
P6
1
248
147K02000063
Shield cover of
DP990EX mainboard
P2
PCS
P7,P8
2
249
147K02000064
Shield cover of
DP990EX mainboard
P3
PCS
P9
1
250
7MDC-4072-11A-W
STP-V shield cover 5
PCS
P10
1
