Sr. No. ITEM DESCRIPTION QTY
1 P12.2151.161.0.PR UPPER COVER PLATE ASSEMBLY 1
2 P12.2151.162.0.PR SIDE COVER ROTOTILLER LH 1
3 P12.2151.163.0.PR SIDE COVER ROTOTILLER RH 1
4 57.003.08.020. SET SCREW - M8X1.25X20 - 8.8 10
5 57.507.08.000. PLAIN PUNCHED WASHER - M08 10
6 57.505.08.000. SPRING WASHER - M08 10
7 57.002.12.120. BOLT- M12 x 1.75 x 120 - 8.8 3
8 57.507.12.000. PLAIN PUNCHED WASHER - M12 6
9 57.505.12.000. SPRING WASHER - M12 3
10 57.006.12.000. NUT - M12X1.75 - GR.8 3
11 P12.2151.085.0.PR RUBBER FENDER PLATE ASSEMBLY 1
12 57.006.06.000. NUT - M8 X1.25 - GR.8 7
13 57.003.06.020. SET SCREW - M6 x 1 x 20 - 8.8 7
14 57.507.06.000. PLAIN PUNCHED WASHER - M6 7
15 P15.2101.019.0.PR SPACER SIDE COVER PLATE 2
16 57.507.10.000. PLAIN PUNCHED WASHER - M10 14
17 57.505.10.000. SPRING WASHER - M10 8
18 57.505.06.000. SPRING WASHER - M6 7
19 57.003.10.030. SET SCREW - M10X1.5X30 - 8.8 6
20 57.006.10.000. NUT - M10 X1.5 - GR.8 4
21 P12.2151.154.0.PR SUPPORT LH, ROTOTILLER COVER 1
22 P12.2151.155.0.PR SUPPORT RH, ROTOTILLER COVER 1
23 P12.2051.158.0.PR TAILWHEEL SHOE 1
24 P12.2151.101.0.PR CLAMP ASSEMBLY 1
25 57.003.10.035. SET SCREW - M10X1.5X35 - 8.8 2
26 57.507.16.000. PLAIN PUNCHED WASHER - M16 2
27 P12.2151.152.0.PR FENDER MOUNTING PLATE ASSLY 1
ROTOTILLER COVER ASSEMBLY
