29
OWNERS Manual
8.8.4 Special Designed Side Panel, Brace Plate and Chain Cover for (12 HP)
8.9 Height & Position Setting Working Depth
• To adjust the tilling depth, turn the handle of the tail wheel.
• If the desired tilling depth is not available then loosen tail wheel sleeve clamp and adjust the position of
sleeve to increase depth.
8.10 Rototiller Reverse Locking
• While reversing Mega T, rototiller shaft should not rotate.
• Locking mechanism is provided in machine to prevent it from rotating.
• When transmission lever is kept in reverse slot, it moves reverse locking lever in neutral position, where
it restricts the movement of rototiller Hi-Low lever.
Note: - warranty will get void if reverse locking tempered.
• Get better earthing up in sugarcane operation.
