KIRLOSKAR OIL ENGINES LIMITED
4
3. Technical Specifications
MEGA-T12 LW - S Specifications
Brand Name
MEGA-T12LW - S
Brand Name KMW
Engine
Model P-700
Emission Compliance TREM III Compliant
No. of Cylinder One
Type DI, Horizontal Single Cylinder
Rated Power Output (HP/ KW) 12 / 8.8
Rated RPM 2400
High Idle RPM 2650
Low Idle RPM 1200
Bore x Stroke (mm) 95 x 98
Displacement (cc) 694
Max Torque (Nm) 42
Max Torque RPM 1400
Type of Cooling Water cooled
Engine oil SAE15W40 CF4
Engine oil sump capacity (L) 1.3 litre
Air cleaner Oil Bath Type
Fuel Tank Capacity (L) 8.0 Liters
Transmission
Make KOEL (Kirloskar Oil Engines Ltd.)
No. of Gears 6 Forward + 2 Reverse
Speed Chart (kmph)
Low Range
1st
1.72
2nd
3.13
3rd
3.93
Rev
1.43
High Range
1st
6.15
2nd
11.21
3rd
14.05
Rev
5.12
Gear box oil SAE 80 W 90
Gear box oil capacity (L)
6.5 Liters
Chain Casing Oil
SAE 80 W 90
0.5 Liters
LH Support housing Grease filled
Type of grease General purpose grease
