5
OWNERS Manual
Technical Specifications
Main Clutch
Type Multiplate clutch
Clutch lining material Organic
Clutch plate dia 160 mm
Method of operation\By Hand lever on LHS Handle Bar
Brake
Transmission Brake optional available
Parking Brake Provided on transmission
Actuation Method
Lever combined with Clutch actuating lever
(by pulling towards rearmost position on the
quadrant)
Steering
Method Independent jaw clutch for each wheel
Actuation By levers provided on the handle.
Rotary Tiller
No. of blades Wet Land: 20 Sugar Cane Centralised: 22
Type of blades Hatchet Blade & Straight blade
Side chain drive Chain drive
Rotor Shaft Removable
Bearing Sealing Special Multi lip seal
Rotor speeds :
By Range Selection (Rotor Low & Rotor High)
250 RPM & 364 RPM
By Sproket interchanging (12T Driving & 14 T Driven) 184 RPM & 267 RPM
Electricals
Head Lamp 35 W /35 W
Overall
Dimensions
Length (without seating attachment)
2500 mm
Width
860 mm
Height
1320 mm (Level surface)
Seating arrangement Optional available
Weight
Without rotary tiller
380Kg
With rotary tiller
450 Kg
Tyres
Drive Tyres 6.00 -12 - Pneumatic, Traction Type
Tail Wheel 3.5 - 8.00 Pneumatic
Recommended air pressure
For Field 1.68 kgf/cm
2
For Road 1.54 kgf/cm
2
Track Width
Standard supply condition
710 mm
Track width Standard
Method of track adjustment By reversing wheel rim
