KIRLOSKAR OIL ENGINES LIMITED
24
• Don’t open adjusting screw to extreme end other will be the steering gear jaw will be partially
l
oaded during operation & will damage it.
Caution:
Don’t use steering levers on slope.
8.5 Throttle Control System adjustment
• Start the engine and loosen control yoke lever screw and hold cable. Now keep throttle lever at
minimum position i.e. towards engine.
• Move speed control knob to obtain a stable idle, below the speed at which the tiller tines begin to
t
urn.
Steering lever lock nut
Setting Screw
