Sr. No. ITEM DESCRIPTION QTY. Sr. No. ITEM DESCRIPTION QTY.
1 P12.0908.051.0.PR MAIN GEAR BOX HOUSING 1 49 P12.0908.002.0.PR GEAR, COUNTER SHAFT 1
2 P12.0908.034.0.PR SHAFT, GEAR INTERMEDIATE REDUCTION 2 1 50 P12.0908.015.0.PR GEAR, SECOND DRIVE 1
3 P12.0908.007.0.PR GEAR INTERMEDIATE REDUCTION 1 51 P12.0908.394.0.PR LOCKING PLATE 1
4 P12.0908.098.0.PR SNAP RING 1 52 P12.0908.003.0.PR GEAR, 1ST SPEED 1
5 P12.0908.008.0.PR GEAR STEERING 2 53 P12.0908.037.0.PR SHAFT, ROTOTILLER HI-LOW 1
6 P15.0901.076.0.PR STEERING SPRING 2 54 P12.0908.024.0.PR GEAR, ROTORY HI-LOW 1
7 P15.0901.051.0.PR PROTECTING RING 2 55 P12.0908.023.0.PR GEAR, ROTOTILLER DRIVEN-2 1
8 P15.0901.565.0.PR BEARING 6304 3 56 P12.0908.109.0.PR SPACER FOR ROTOR HI-LOW SHAFT 1
9 P12.0908.083.0.PR GASKET COVER INTERMEDIATE SHAFT 2 57 P12.0908.043.0.PR RAIL HIGH LOW RANGE 1
10 P12.0908.053.0.PR END COVER INTERMEDIATE SHAFT 2 58 P12.0908.347.0.PR SHIFTING FORK HIGH-LOW 1
11 50.505.06.000. SPRING WASHER - M6 24 59 P12.0908.042.0.PR RAIL 2ND AND 3RD 1
12 50.003.06.016. SET SCREW - M6X1X16 12 60 P12.0908.346.0.PR SHIFTING FORK 2ND AND 3RD 1
13 50.010.12.035. STUD - M12X1.75X35 6 61 P12.0908.041.0.PR RAIL 1ST AND REVERSE 1
14 50.505.12.000. SPRING WASHER - M12 6 62 P12.0908.345.0.PR SHIFTING FORK 1ST AND REVERSE 1
15 50.006.12.000. NUT - M12X1.75 6 63 P12.0908.444.0.PR RAIL ROTARY FORK 1
16 P15.0901.561.0.PR BEARING 6204 4 64 P12.0908.348.0.PR SHIFTING FORK ROTOR GEAR 1
17 P12.0908.103.0.PR WASHER, HI-LOW SHAFT 2 65 P15.0901.075.0.PR SPRING, SHIFTING FORK 3
18 P12.0908.033.0.PR SHAFT, HIGH LOW 1 66 50.529.09.000. STEEL BALL DIA 8 3
19 P12.0908.059.0.PR BRAKE RING 1 67 P12.0908.338.0.PR BRACKET FOR LOCKING PIN 1
20 P12.0908.071.0.PR SNAP RING FOR GEAR 2 68 P12.0908.039.0.PR LOCKING PIN 1
21 P12.0908.006.0.PR GEAR 1, INTERMEDIATE DRIVING 1 69 50.505.05.000. SPRING WASHER - M5 3
22 P12.0908.005.0.PR GEAR, HI-LOW 1 70 50.011.05.014. ALLEN SCREW, M5X14 3
23 P12.0908.035.0.PR SHAFT REVERSE GEAR 1 71 P12.0908.395.0.PR SHIFTING FORK STEERING LEFT 2
24 P12.0908.122.0.PR WASHER FOR REVERSE IDLER SHAFT 1 72 P12.0908.123.0.PR WASHER REVERSE IDLER SHAFT 1
25 P12.0908.017.0.PR GEAR REVERSE WITH BUSH 1 73 P15.1101.085.0.PR O RING 16X2.4 2
26 P12.0908.018.0.PR GEAR REVERSE 1 74 P12.0908.084.0.PR GASKET, STEERING COVER 1
27 P12.0908.106.0.PR BUSH, GEAR REVERSE 2 75 P12.0908.352.0.PR COVER, STEERING 1
28 P12.0908.104.0.PR BUSH, REVERSE GEAR SHAFT 1 76 P12.0908.099.0.PR GASKET RH SIDE, MAIN GEAR BOX 1
29 50.508.10.000. COPPER WASHER 12*18 1 77 P12.0908.151.0.PR COVER PLATE, RH FOR GEARBOX 1
30 50.602.12.000. CORE PLUG-HEXAGONAL HEAD - M12 1 78 50.003.06.020. SET SCREW - M6X1X20 12
31 P12.0908.115.0.PR OUTER SPACER 1 79 57.003.06.025. SET SCREW - M6X1X25 3
32 P12.0908.088.0.PR RETAINING RING 1 80 50.505.08.000. SPRING WASHER - M8 3
33 P12.0908.101.0.PR SLEEVE 1 81 50.003.08.016. SET SCREW - M8X1.25X16 2
34 P12.0908.068.0.PR BEARING 6004 2 82 50.003.08.025. SET SCREW - M8X1.25X25 1
35 P12.0908.102.0.PR BUSH SPACER, MAIN SHAFT 1 83 50.401.08.020. DOWEL PIN 8X20 2
36 P12.0908.001.0.PR GEAR, DRIVING MAIN SHAFT 1 84 50.401.10.030. DOWEL PIN 10X25 2
37 P12.0908.016.0.PR GEAR, MAIN SHAFT 2ND 1 85 2H.035.02.0.00 PRECOATED DRAIN PLUG 1
38 P12.0908.031.0.PR SHAFT, MAIN 1 86 50.010.14.040. STUD - M14X2X40 6
39 P15.0901.094.0.PR SNAP RING 2 87 50.507.14.000. PLAIN PUNCHED WASHER - M14 2
40 P12.0908.004.0.PR GEAR, MAIN SHAFT 1 88 50.505.14.000. SPRING WASHER - M14 2
41 P15.0901.566.0.PR BEARING 6305 3 89 50.006.14.000. NUT - M14X2 2
42 P15.0901.562.0.PR BEARING 6205 2 90 50.008.14.000. LOCK NUT - M14X2 2
43 P12.0908.108.0.PR SPACER FOR ROTOR IDLER SHAFT 1 91 P12.0908.086.0.PR GASKET, REAR FACE MAIN GEAR BOX 1
44 P12.0908.036.0.PR SHAFT INTERMEDIATE 1 92 F6.024.47.0.00 O-RING FOR DRAIN PLUG 1
45 P12.0908.022.0.PR GEAR ,ROTOTILLER DRIVEN-1 1 93 50.529.11.000. STEEL BALL DIA 9 1
46 P12.0908.107.0.PR SPACER FOR ROTOR IDLER GEAR 1 94 P12.0908.475.0.PR SPRING, SHIFTING FORK 1
47 P12.0908.021.0.PR GEAR, ROTOTILLER DRIVING INTERMEDIATE 1 # P12.0908.116.0.PR FILLER PLATE 0.5 THK. AR
48 P12.0908.032.0.PR COUNTER SHAFT 1 # P12.0908.117.0.PR FILLER PLATE 1.0 THK. AR
# P12.0908.118.0.PR FILLER PLATE 1.5 THK. AR
GEARBOX ASSEMBLY
