Sr. No. ITEM DESCRIPTION QTY
1 P12.1208.151.0.PR BASE FRAME ASSEMBLY 1
2 50.003.14.035. SET SCREW - M14X2X35 - 8.8 4
3 50.507.14.000. PLAIN PUNCHED WASHER - M14 4
4 50.505.14.000. SPRING WASHER - M14 4
5 50.006.12.000. NUT - M12X1.75 - GR.8 13
6 50.505.12.000. SPRING WASHER - M12 10
7 50.507.12.000. PLAIN PUNCHED WASHER - M12 7
8 50.010.12.035. STUD - M12X1.75X35 - 8.8 8
9 P12.1201.141.0.PR MOUNTING PLATE FRONT 1
10 P12.1205.142.0.PR MOUNTING PLATE REAR 1
11 P12.1201.123.0.PR STUD ADJUSTING 1
12 P15.1201.004.0.PR GUARD ASSY, FRONT 1
13 57.006.10.000. NUT - M10X1.5 - GR.8 2
14 57.505.10.000. SPRING WASHER - M10 2
15 57.507.10.000. PLAIN PUNCHED WASHER - M10 2
16 P12.1201.224.0.PR PIVOT BOLT, FRONT STAND 2
17 P15.1201.021.0.PR SPRING, FRONT STAND 1
18 P15.1201.103.0.PR STAND ASSEMBLY 1
BASEFRAME ASSEMBLY
