4-20
REMOVING THE OVEN DOOR
1. Open the microwave oven door. 2. Use a 1/4″ drill bit, and drill the head off the
rivet on the right side of the oven door.
NOTE: A new rivet is supplied with the
replacement oven door (a rivet must be
used in this application to deter disassem-
bly by customers).
3. Remove the T10 Torx screws from the left
and right sides of the oven door, and
remove the door.
Door Screw
Door Rivet
To Next Page
