4-19
REMOVING THE TURNTABLE MOTOR
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
WARNING
1. Unplug microwave oven or disconnect
power.
2. Remove the microwave oven from its
mounting location.
3. Open the oven door and remove the dish
holder from the turntable motor shaft.
4. Lay the microwave oven on its rear panel
so you can access the bottom of the unit.
5. Remove the two T20 Torx screws from the
turntable motor.
6. Disconnect the two wires from the turn-
table motor and remove the motor.
Dish Holder
Turntable Motor
Screws
Turntable Motor Wires
To Next Page
