7-3
STRIP CIRCUITS
MICROWAVE OVEN COOKING
1 4 2 1 4 1
H
V
S
L1
N
20A Fuse
250 mA Fuse
Secondary
Interlock Switch
Primary
Interlock Switch
MW Relay
High Voltage
System
Control
Inverter
Power Supply
Turntable
Motor
Fan Motor
Turntable
Relay
Lamp Relay
Fan Relay
Filter Filter
No Load
Thermostat
Cavity
Thermostat
Magnetron
Thermostat
Cavity Lamp
