Name of parts
Single speed type / Dual speed pole change type
Dual speed inverter type (Basic main body B/C type)
Dual speed inverter type (Basic main body D/E/F type)
Inverter
Controller cover
Plate
Limit switch
Packing C
Braking resistor
Name plate
Resistor cover
Interface board
Controller cover
Plate
Limit switch
Packing C
Inverter
Controller cover
Braking resistor
Name plate
Plate
Limit switch
Resistor cover
Interface board
Packing C
