8
Safety Notes for Battery
Please use a battery that is the same type as the
one included.
Please use the included USB cable and AC
adapter to charge the battery inside the
camera.
If battery luid leaks inside the camera, contact
our customer service department immediately.
If battery luid leaks onto your skin, rinse your
skin with clean water and seek immediate
medical attention.
Disposal of used batteries should be carried
out in accordance with your local (national or
regional) regulations.
To prevent the battery from being damaged,
do not drop the battery or allow it to hit solid
objects or to be scratched by foreign objects.
Do not let the battery come in contact with
metal objects (including coins) to avoid short
circuiting, discharging, excessive heat or
possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep
the battery contacts dry.
Do not heat the battery or throw it into a ire to
avoid a possible explosion.
Do not store the battery in a hot environment or in
direct sunlight.
If the battery overheats during charging or use,
stop charging or stop use immediately. Turn o
the product, remove the battery carefully and
wait until it cools down.
When the camera is stored for a long period of
time, remove the battery and keep it in a safe,
dry place that is not accessible to infants and
children.
In colder environments, the performance of the
battery could be noticeably reduced.
When you install the battery, align the battery
markings according to the positive and
negative markings inside the camera battery
compartment. Never force the battery into the
battery compartment.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kodak PIXPRO WPZ2 and is the answer not in the manual?

Kodak PIXPRO WPZ2 Specifications

General IconGeneral
Megapixel16.76 MP
Camera typeCompact camera
Sensor typeBSI CMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedEXIF, JPEG
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)(4:3) 16MP: 4608x3456, 10MP: 3648x2736, 5MP: 2592x1944, 3MP: 2048x1536, 0.3MP: 640x480, (3:2) 14MP: 4608x3072, (16:9) 12MP: 4608x2592, 2MP: 1920x1080
Digital zoom6 x
Optical zoom4 x
Combined zoom24 x
Focal length range4.9 - 19.6 mm
Lens structure (elements/groups)7/7
Maximum focal length (35mm film equiv)108 mm
Minimum focal length (35mm film equiv)27 mm
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed4 s
Flash modesAuto, Fill-in, Forced off, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 2.4 m
Flash range (wide)0.3 - 5.2 m
Flash recharging time6 s
Memory slots1
Internal memory8 MB
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Maximum memory card size32 GB
PictBridge-
USB version2.0
USB connectorMicro-USB
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)-10 - 40 °C
Operating relative humidity (H-H)0 - 90 %
Battery typeLB-015
Battery voltage3.7 V
Battery capacity700 mAh
Product colorBlue
Waterproof up to15 m
White balanceAuto, Cloudy, Daylight, Fluorescent, Incandescent, Manual, Underwater
Shooting modesAuto, Movie
Self-timer delay- s
Display diagonal2.7 \
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200
ISO sensitivity (max)3200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
FocusTTL
Focus adjustmentAuto
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus
Normal focusing range (tele)1 — ∞ m
Normal focusing range (wide)0.6 — ∞ m
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Weight and Dimensions IconWeight and Dimensions
Depth52.4 mm
Width103.2 mm
Height66.7 mm
Weight176 g
