Chapter 4 Setup after installation MDC-7000/7900 Series
4-8 0092669002-07
Note: Range unit can be changed by [DISPLAY] => [RANGE UNIT] menu.
Fig.4.4. Initial range scale setting
MDC-7025/MDC-7925
>MAINTENANCE >MAINTENANCE >MAINTENANCE
>STARTUP >STARTUP >STARTUP
>RANGE ENABLE >RANGE ENABLE >RANGE ENABLE
0.0625 OFF 0.125 ON 0.0625 OFF
0.125 ON 0.25 ON 0.125 ON
0.25 ON 0.5 ON 0.25 ON
0.5 ON 1 OFF 0.5 ON
0.75 ON 1.5 OFF 0.75 ON
1 OFF 2 ON 1 OFF
1.5 ON 3 OFF 1.5 ON
2 OFF 4 ON 2 OFF
3 ON 5 OFF 3 ON
4 OFF 6 OFF 4 OFF
5 OFF 8 ON 5 OFF
6 ON 10 OFF 6 ON
8 OFF 12 OFF 8 OFF
10 OFF 16 ON 10 OFF
12 ON 20 OFF 12 ON
16 OFF 24 OFF 16 OFF
20 OFF 32 ON 20 OFF
24 ON 36 OFF 24 ON
32 OFF 40 OFF 32 OFF
36 OFF 48 OFF 36 OFF
40 OFF 50 OFF 40 OFF
48 ON 64 ON 48 ON
50 OFF 80 OFF 50 OFF
64 OFF 96 ON 64 OFF
80 OFF 100 OFF 80 OFF
96 ON 120 OFF 96 ON
100 OFF 144 ON 100 OFF
120 OFF 200 OFF 120 OFF
144 OFF 144 OFF
Range unit：sm, kf, ky
Range unit：NM
Range unit：km
