Chapter 4 Setup after installation MDC-7000/7900 Series
4-20 0092669002-07
4.2.8.1 Setting of TLL output
The position of marks and a cursor can be output to external devices.
Select the kinds of TLL sentences to be output.
(1) [MAINTENANCE] => [I/O] => [OUTPUT] => [TLL OUT] => Select [TT], [MARK] or [TARGET], and
press ENT key.
Set values: TT, MARK, TARGET
TT: The position of automatic tracking target captured is output with the cycle set in “4.2.8 Setting of
serial output”.
MARK: The positions marked in drawing will be output at every marking.
TARGET: TLL output is set on the function key. Every press of the function key allows the position of
cursor to be output as TLL on the screen.
4.2.8.2 Setting of ALR output port
Signal (ALR) of alarm generated by radar can be output to external devices. In addition, it is possible to
stop the alarm from the radar with receipt of signals (ACK) to stop it from the external devices.
Select a port for transmission of fault alarm in radar to external devices.
(1) [MAINTENANCE] => [I/O] => [OUTPUT] => [ALR OUT PORT] => Select [J3], [J5], [J6], [OP1] or
[OP2], and press ENT key.
Set values: J3, J5, J6, OP1, OP2
4.2.8.3 Setting of ALF output port
Signal (ALF) of alarm generated by radar can be output to external devices. In addition, it is possible to
stop the alarm from the radar with receipt of signals (ACK) to stop it from the external devices.
Select a port for transmission of fault alarm in radar to external devices.
(1) [MAINTENANCE] => [I/O] => [OUTPUT] => [ALF OUT PORT] => Select [J3], [J5], [J6], [OP1] or
[OP2], and press ENT key.
Set values: J3, J5, J6, OP1, OP2
To Next Page
