MDC-7000/7900 Series Chapter 4 Setup after installation
0092669002-07 4-17
4.2.5.1 How to input the COG value by manual
(1) [MAINTENANCE] => [I/O] => [COG/SOG] => [COG MAN] => [VALUE] will show the current setting
of the input value by highlighting the last digit value by the trackball.
(2) Move the TRACKBALL up or down to set the value. Press ENT key to save the set result.
Setting value: 0.0 to 359.9°
Note: The manual input data is displayed with yellow color.
4.2.5.2 How to input the SOG value by manual
(1) [MAINTENANCE] => [I/O] => [COG/SOG] => [SOG MAN] => [VALUE] will show the current setting
of the input value by highlighting the last digit value by the trackball.
(2) Move the TRACKBALL up or down to set the value. Press ENT key to save the set result.
Setting value: 0.0 to 100.0 kn
Note: The manual input data is displayed with yellow color.
4.2.6 Setting of SET/DRIFT to be used for CURRENT mode
When [CURRENT] is selected in “4.2.4” (STW) and “4.2.5” (COG/SOG), the device to input SET/DRIFT
is selected.
Select the sensor of SET/DRIFT when [CURRENT] is selected at STW and COG/SOG.
(1) [MAINTENANCE] => [I/O] => [SET/DRIFT] => [SET/DRIFT] => [VDR] or [MAN], and press ENT
key.
Set values: VDR, MAN
MAN: Use SET/DRIFT value manually input.
Note: AIS display does not work when [MAN] is selected.
4.2.6.1 How to input the SET/DRIFT value by manual
(1) [MAINTENANCE] => [I/O] => [SET/DRIFT] => [SET MAN] => [VALUE] will show the current setting
of the input value by highlighting the last digit value by the trackball.
(2) Move the TRACKBALL up or down to set the value. Press ENT key to save the set result.
Setting value: 0.0 to 359.9°
(3) [MAINTENANCE] => [I/O] => [SET/DRIFT] => [DRIFT MAN] => [VALUE] will show the current
setting of the input value by highlighting the last digit value by the trackball.
(4) Move the TRACKBALL up or down to set the value. Press ENT key to save the set result.
Setting value: 0.0 to 100.0 kn
Note: The manual input data is displayed with yellow color.
