Chapter 4 Setup after installation MDC-7000/7900 Series
4-12 0092669002-07
4.2 Setup I/O Interface
For display mode, TT(ARPA), true ship’s trail and own ship’s trail, it is necessary to input ship’s bearing
data and ship’s speed data from other devices. In addition, for AIS, mapping function, display of own
ship’s information and display of latitude and longitude, it is necessary to input latitude and longitude
data of own ship’s data. In order to use these data, set the following menu items after connection in
accordance with 3.4 “Cable connection to a Display unit”.
Note: Refer to “4.2.2 How to use without NMEA input connection” for the method to use without
inputting NMEA data.
Example display: Press MENU key to display “Menu” and select [MAINTENANCE] => [I/O]
Figure 4.6 I/O menu
>MAINTENANCE
>I/O
HDG
GYRO
OFFSET
STW
DLOG
COG/SOG
DLOG
DLOG
POSITION
DGPS
OFFSET
MAN
DATUM REF
LOCAL
SET/DRIFT
MAN
TIME
GPS
TIME ZONE
OUTPUT
INPUT
BAUDRATE
KGC SET
JB-35 SET
SERIAL MONITOR
>
295.5°
0.0°
>
6.6kn
>
295.5°
6.6kn
>
35
o
14.722N
139
o
48.122E
DTM
0.000N
0.000E
W84
W84
>
0.0
o
0.0kn
>
01/01/16
07:57
00:00
>
>
>
>
>
>
Select heading input source
Talker device name and heading value
Offset value of heading input
Select STW input source
Talker device name and speed value
Select COG/SOG input source
Talker device name and course value
Talker device name and speed value
Select position input source
Talker device name and LAT/LON value
Select position offset input source
Offset input source name and offset value
Reference datum name
Local datum name
Select SET/DRIFT input source
Talker device name and SET data
DRIFT data
Select time input source
Talker device name and date
Clock
Time zone value
Setup output NMEA sentences
Setup input NMEA sentences
Setup NMEA data baud rate
Setup KODEN GPS compass
Setup junction box JB-35
Monitor of input NMEA serial data
