Kohler 6VSG Service Manual

56 Section 4 Troubleshooting TP-6844 1/13
Figure 4-3 Status Messages Displayed on the VSC Controller
Fuel Spill * Notice The digital output for Fuel Spill (PIM) is
active (contacts closed), indicating any of
the digital inputs for Fuel Tank Leak
Warning, Fuel Tank Leak Shutdown,
Engine Fuel Level Warning or Engine
Fuel Level Critically High (PIM) is active
(low).
Check customer equipment
connected to the PIM module.
Gen Running Notice The digital output for Generator Running
(PIM) is active (contacts closed),
indicating the generator is running.
Check controller front panel
buttons for potential RUN
command. If in AUTO, check
remote start lines.
Low Fuel * Notice The digital output for Low Fuel (PIM) is
active (contacts closed), indicating any of
the digital inputs for Low Fuel Pressure
Warning, Low Fuel Level Warning or Low
Fuel Level Shutdown (PIM) is active
(low).
Check customer equipment
connected to the PIM module.
Minor Fault Notice The digital output for Minor Fault (PIM) is
active (contacts closed), indicating either
the digital input for Ground Fault Indicator
Warning (PIM) is active (low) or the
controller detected Low Cranking
Voltage.
Check customer equipment
connected to the PIM module.
Check cranking battery
condition.
Rmt StartCmd
(Remote Start Command Issued)
Notice The controller has received a remote start
signal while the master switch is in AUTO,
and will go to normal running.
Verify remote start signal.
Run Btn Ack
(Run Button Acknowledged)
Notice The RUN button on the controller has
been pushed.
NA
Start Delay
(Engine Start Delay Active)
Notice The digital output for Engine Start Delay
(PIM) is active (contacts closed),
indicating the engine is in between active
cranking cycles.
NA
System Ready Notice The digital output for System Ready
(PIM) is active (contacts closed),
indicating the generator has no active
faults or warnings.
NA
VSpdStartCmd (Variable Speed
Start Command)
Notice A diagnostic exercise request has been
received by the controller.
Check for a remote exercise
command from OnCue.
* Programmable Interface Module (PIM) required.
Fault Message Action Description/Comments Check
