Appendix E Common Hardware List
The Common Hardware List lists part numbers and dimensions for common hardware items.
American Standard
Part No. Dimensions
Hex Head Bolts (Grade 5)
X-465-17
X-465-6
X-465-2
X-465-16
X-465-18
X-465-7
X-465-8
X-465-9
X-465-10
X-465-11
X-465-12
X-465-14
X-465-21
X-465-25
X-465-20
1/4-20 x .38
1/4-20 x .50
1/4-20 x .62
1/4-20 x .75
1/4-20 x .88
1/4-20 x 1.00
1/4-20 x 1.25
1/4-20 x 1.50
1/4-20 x 1.75
1/4-20 x 2.00
1/4-20 x 2.25
1/4-20 x 2.75
1/4-20 x 5.00
1/4-28 x .38
1/4-28 x 1.00
X-125-33
X-125-23
X-125-3
X-125-31
X-125-5
X-125-24
X-125-34
X-125-25
X-125-26
230578
X-125-29
X-125-27
X-125-28
X-125-22
X-125-32
X-125-35
X-125-36
X-125-40
5/16-18 x .50
5/16-18 x .62
5/16-18 x .75
5/16-18 x .88
5/16-18 x 1.00
5/16-18 x 1.25
5/16-18 x 1.50
5/16-18 x 1.75
5/16-18 x 2.00
5/16-18 x 2.25
5/16-18 x 2.50
5/16-18 x 2.75
5/16-18 x 3.00
5/16-18 x 4.50
5/16-18 x 5.00
5/16-18 x 5.50
5/16-18 x 6.00
5/16-18 x 6.50
X-125-43
X-125-44
X-125-30
X-125-39
X-125-38
5/16-24 x 1.75
5/16-24 x 2.50
5/16-24 x .75
5/16-24 x 2.00
5/16-24 x 2.75
X-6238-2
X-6238-10
X-6238-3
X-6238-11
X-6238-4
X-6238-5
X-6238-1
X-6238-6
X-6238-17
X-6238-7
X-6238-8
X-6238-9
X-6238-19
X-6238-12
X-6238-20
X-6238-13
X-6238-18
X-6238-25
3/8-16 x .62
3/8-16 x .75
3/8-16 x .88
3/8-16 x 1.00
3/8-16 x 1.25
3/8-16 x 1.50
3/8-16 x 1.75
3/8-16 x 2.00
3/8-16 x 2.25
3/8-16 x 2.50
3/8-16 x 2.75
3/8-16 x 3.00
3/8-16 x 3.25
3/8-16 x 3.50
3/8-16 x 3.75
3/8-16 x 4.50
3/8-16 x 5.50
3/8-16 x 6.50
Part No. Dimensions
Hex Head Bolts (Grade 5) cont.
X-6238-14
X-6238-16
X-6238-21
X-6238-22
3/8-24 x .75
3/8-24 x 1.25
3/8-24 x 4.00
3/8-24 x 4.50
X-6024-5
X-6024-2
X-6024-8
X-6024-3
X-6024-4
X-6024-11
X-6024-12
7/16-14 x .75
7/16-14 x 1.00
7/16-14 x 1.25
7/16-14 x 1.50
7/16-14 x 2.00
7/16-14 x 2.75
7/16-14 x 6.50
X-129-15
X-129-17
X-129-18
X-129-19
X-129-20
X-129-21
X-129-22
X-129-23
X-129-24
X-129-25
X-129-27
X-129-29
X-129-30
X-463-9
X-129-44
1/2-13 x .75
1/2-13 x 1.00
1/2-13 x 1.25
1/2-13 x 1.50
1/2-13 x 1.75
1/2-13 x 2.00
1/2-13 x 2.25
1/2-13 x 2.50
1/2-13 x 2.75
1/2-13 x 3.00
1/2-13 x 3.50
1/2-13 x 4.00
1/2-13 x 4.50
1/2-13 x 5.50
1/2-13 x 6.00
X-129-51
X-129-45
X-129-52
1/2-20 x .75
1/2-20 x 1.25
1/2-20 x 1.50
X-6021-3
X-6021-4
X-6021-2
X-6021-1
273049
X-6021-5
X-6021-6
X-6021-7
X-6021-12
X-6021-11
X-6021-10
5/8-11 x 1.00
5/8-11 x 1.25
5/8-11 x 1.50
5/8-11 x 1.75
5/8-11 x 2.00
5/8-11 x 2.25
5/8-11 x 2.50
5/8-11 x 2.75
5/8-11 x 3.75
5/8-11 x 4.50
5/8-11 x 6.00
X-6021-9 5/8-18 x 2.50
X-6239-1
X-6239-8
X-6239-2
X-6239-3
X-6239-4
X-6239-5
X-6239-6
3/4-10 x 1.00
3/4-10 x 1.25
3/4-10 x 1.50
3/4-10 x 2.00
3/4-10 x 2.50
3/4-10 x 3.00
3/4-10 x 3.50
X-792-1
X-792-5
X-792-8
1-8 x 2.25
1-8 x 3.00
1-8 x 5.00
Part No. Dimensions Type
Hex Nuts
X-6009-1 1-8 Standard
X-6210-3
X-6210-4
X-6210-5
X-6210-1
6-32
8-32
10-24
10-32
Whiz
Whiz
Whiz
Whiz
X-6210-2
X-6210-6
X-6210-7
X-6210-8
X-6210-9
X-6210-10
X-6210-11
X-6210-12
X-6210-15
X-6210-14
1/4-20
1/4-28
5/16-18
5/16-24
3/8-16
3/8-24
7/16-14
1/2-13
7/16-20
1/2-20
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
Spiralock
X-85-3
X-88-12
X-89-2
5/8-11
3/4-10
1/2-20
Standard
Standard
Standard
Hex Nuts
Part No. ID OD Thick
Bolt/
Screw
X-25-46
X-25-9
X-25-48
X-25-36
X-25-40
X-25-85
X-25-37
X-25-34
X-25-26
X-25-15
X-25-29
X-25-127
.125
.156
.188
.219
.281
.344
.406
.469
.531
.656
.812
1.062
.250
.375
.438
.500
.625
.687
.812
.922
1.062
1.312
1.469
2.000
.022
.049
.049
.049
.065
.065
.065
.065
.095
.095
.134
.134
#4
#6
#8
#10
1/4
5/16
3/8
7/16
1/2
5/8
3/4
1
