28 Section 3 Controller TP-6844 1/13
Figure 3-3
Figure 3-3 USB Connection
3.3 Controller Parameters
Adjustable parameter settings can be changed using a
personal computer (or laptop) with Kohler SiteTech
software. See Section 3.2, SiteTech and OnCue
Software for USB connection information. See the
SiteTech Operation Manual, TP-6701, for general
software operation instructions.
Some parameter settings can also be changed at the
VSC controller. See the generator set operation
manual for instructions to navigate through the
controller menus and change settings.
3.3.1 Genset System Menu
The genset system menu displays the system
information shown in Figure 3-4. Generator sets are
factory-set and should not require changes to the
system settings in the field.
A Kohler-authorized distributor or dealer can adjust
these settings, if necessary. If the system settings
require adjustment, see Installation Manual for
instructions.
Note: Use caution when navigating the controller
menus. In some menus, pressing the Select
button can enable editing of the controller
settings. Changing the settings to incorrect
values can adversely affect generator set
operation or render the unit inoperable.
System Parameters for Battery Bank Charging
The following system parameters can be viewed in the
Genset System menu on the user interface on the
generator set’s VSC controller.
• System Voltage
• Auto Start Voltage
• Auto Stop Load (%)
• Load Limit
Note: Changing these settings can damage your
generator set and batteries. Always refer to the
information provided by the battery bank
manufacturer for the correct voltage and charge
current limits for your batteries. See the
Operation Manual for instructions to change
settings, if necessary.
1. USB cable connection to PC 2. USB cable connection to controller
