Hex head bolts are hardness grade 8.8 unless noted.
Metric
Part No. Dimensions
Hex Head Bolts (Partial Thread)
M931-05055-60
M931-06040-60
M931-06055-60
M931-06060-60
M931-06060-SS
M931-06070-60
M931-06070-SS
M931-06075-60
M931-06090-60
M931-06145-60
M931-06150-60
M5-0.80 x 55
M6-1.00 x 40
M6-1.00 x 55
M6-1.00 x 60
M6-1.00 x 60
M6-1.00 x 70
M6-1.00 x 70
M6-1.00 x 75
M6-1.00 x 90
M6-1.00 x 145
M6-1.00 x 150
M931-08035-60
M931-08040-60
M931-08045-60
M931-08050-60
M931-08055-60
M931-08055-82
M931-08060-60
M931-08070-60
M931-08070-82
M931-08075-60
M931-08080-60
M931-08090-60
M931-08095-60
M931-08100-60
M931-08110-60
M931-08120-60
M931-08130-60
M931-08140-60
M931-08150-60
M931-08200-60
M8-1.25 x 35
M8-1.25 x 40
M8-1.25 x 45
M8-1.25 x 50
M8-1.25 x 55
M8-1.25 x 55*
M8-1.25 x 60
M8-1.25 x 70
M8-1.25 x 70*
M8-1.25 x 75
M8-1.25 x 80
M8-1.25 x 90
M8-1.25 x 95
M8-1.25 x 100
M8-1.25 x 110
M8-1.25 x 120
M8-1.25 x 130
M8-1.25 x 140
M8-1.25 x 150
M8-1.25 x 200
* This metric hex bolt’s hardness
is grade 10.9.
M931-10040-82
M931-10040-60
M931-10045-60
M931-10050-60
M931-10050-82
M931-10055-60
M931-10060-60
M931-10065-60
M931-10070-60
M931-10080-60
M931-10080-82
M931-10090-60
M931-10090-82
M931-10100-60
M931-10110-60
M931-10120-60
M931-10130-60
M931-10140-60
M931-10180-60
M931-10235-60
M931-10260-60
M960-10330-60
M10-1.25 x 40*
M10-1.50 x 40
M10-1.50 x 45
M10-1.50 x 50
M10-1.25 x 50*
M10-1.50 x 55
M10-1.50 x 60
M10-1.50 x 65
M10-1.50 x 70
M10-1.50 x 80
M10-1.25 x 80*
M10-1.50 x 90
M10-1.50 x 90*
M10-1.50 x 100
M10-1.50 x 110
M10-1.50 x 120
M10-1.50 x 130
M10-1.50 x 140
M10-1.50 x 180
M10-1.50 x 235
M10-1.50 x 260
M10-1.25 x 330
M931-12045-60
M960-12050-60
M960-12050-82
M931-12050-60
M931-12050-82
M931-12055-60
M931-12060-60
M931-12060-82
M931-12065-60
M931-12075-60
M931-12080-60
M931-12090-60
M931-12100-60
M931-12110-60
M12-1.75 x 45
M12-1.25 x 50
M12-1.25 x 50*
M12-1.75 x 50
M12-1.75 x 50*
M12-1.75 x 55
M12-1.75 x 60
M12-1.75 x 60*
M12-1.75 x 65
M12-1.75 x 75
M12-1.75 x 80
M12-1.75 x 90
M12-1.75 x 100
M12-1.75 x 110
Part No. Dimensions
Hex Head Bolts (Partial Thread), cont.
M960-16090-60
M931-16090-60
M931-16100-60
M931-16100-82
M931-16120-60
M931-16150-60
M16-1.50 x 90
M16-2.00 x 90
M16-2.00 x 100
M16-2.00 x 100*
M16-2.00 x 120
M16-2.00 x 150
M931-20065-60
M931-20090-60
M931-20100-60
M931-20120-60
M931-20140-60
M931-20160-60
M20-2.50 x 65
M20-2.50 x 90
M20-2.50 x 100
M20-2.50 x 120
M20-2.50 x 140
M20-2.50 x 160
M931-22090-60
M931-22120-60
M931-22160-60
M22-2.50 x 90
M22-2.50 x 120
M22-2.50 x 160
M931-24090-60
M931-24120-60
M931-24160-60
M931-24200-60
M24-3.00 x 90
M24-3.00 x 120
M24-3.00 x 160
M24-3.00 x 200
Hex Head Bolts (Full Thread)
M933-04006-60 M4-0.70 x 6
M933-05030-60
M933-05035-60
M933-05050-60
M5-0.80 x 30
M5-0.80 x 35
M5-0.80 x 50
M933-06010-60
M933-06012-60
M933-06014-60
M933-06016-60
M933-06020-60
M933-06025-60
M933-06030-60
M933-06040-60
M933-06050-60
M6-1.00 x 10
M6-1.00 x 12
M6-1.00 x 14
M6-1.00 x 16
M6-1.00 x 20
M6-1.00 x 25
M6-1.00 x 30
M6-1.00 x 40
M6-1.00 x 50
M933-07025-60 M7-1.00 x 25
M933-08010-60
M933-08012-60
M933-08016-60
M933-08020-60
M933-08025-60
M933-08030-60
M933-08030-82
M8-1.25 x 10
M8-1.25 x 12
M8-1.25 x 16
M8-1.25 x 20
M8-1.25 x 25
M8-1.25 x 30
M8-1.25 x 30*
M933-10012-60
M961-10020-60
M933-10020-60
M933-10025-60
M961-10025-60
M933-10025-82
M961-10030-60
M933-10030-60
M933-10030-82
M961-10035-60
M933-10035-60
M933-10035-82
M961-10040-60
M10-1.50 x 12
M10-1.25 x 20
M10-1.50 x 20
M10-1.50 x 25
M10-1.25 x 25
M10-1.50 x 25*
M10-1.25 x 30
M10-1.50 x 30
M10-1.50 x 30*
M10-1.25 x 35
M10-1.50 x 35
M10-1.50 x 35*
M10-1.25 x 40
Part No. Dimensions
Hex Head Bolts (Full Thread), cont.
M933-12016-60
M933-12020-60
M961-12020-60F
M933-12025-60
M933-12025-82
M961-12030-60
M933-12030-82
M961-12030-82F
M933-12030-60
M933-12035-60
M961-12040-82
M933-12040-60
M933-12040-82
M12-1.75 x 16
M12-1.75 x 20
M12-1.50 x 20
M12-1.75 x 25
M12-1.75 x 25*
M12-1.25 x 30
M12-1.75 x 30*
M12-1.50 x 30*
M12-1.75 x 30
M12-1.75 x 35
M12-1.25 x 40*
M12-1.75 x 40
M12-1.75 x 40*
M961-14025-60
M933-14025-60
M961-14050-82
M14-1.50 x 25
M14-2.00 x 25
M14-1.50 x 50*
M961-16025-60
M933-16025-60
M961-16030-82
M933-16030-82
M933-16035-60
M961-16040-60
M933-16040-60
M961-16045-82
M933-16045-82
M933-16050-60
M933-16050-82
M933-16060-60
M933-16070-60
M16-1.50 x 25
M16-2.00 x 25
M16-1.50 x 30*
M16-2.00 x 30*
M16-2.00 x 35
M16-1.50 x 40
M16-2.00 x 40
M16-1.50 x 45*
M16-2.00 x 45*
M16-2.00 x 50
M16-2.00 x 50*
M16-2.00 x 60
M16-2.00 x 70
M933-18035-60
M933-18050-60
M933-18060-60
M18-2.50 x 35
M18-2.50 x 50
M18-2.50 x 60
M933-20050-60
M933-20055-60
M20-2.50 x 50
M20-2.50 x 55
M933-24060-60
M933-24065-60
M933-24070-60
M24-3.00 x 60
M24-3.00 x 65
M24-3.00 x 70
Pan Head Machine Screws
M7985A-03010-20
M7985A-03012-20
M3-0.50 x 10
M3-0.50 x 12
M7985A-04010-20
M7985A-04016-20
M7985A-04020-20
M7985A-04050-20
M7985A-04100-20
M4-0.70 x 10
M4-0.70 x 16
M4-0.70 x 20
M4-0.70 x 50
M4-0.70 x 100
M7985A-05010-20
M7985A-05012-20
M7985A-05016-20
M7985A-05020-20
M7985A-05025-20
M7985A-05030-20
M7985A-05080-20
M7985A-05100-20
M5-0.80 x 10
M5-0.80 x 12
M5-0.80 x 16
M5-0.80 x 20
M5-0.80 x 25
M5-0.80 x 30
M5-0.80 x 80
M5-0.80 x 100
M7985A-06100-20 M6-1.00 x 100
Flat Head Machine Screws
M965A-04012-SS M4-0.70 x 12
M965A-05012-SS
M965A-05016-20
M965A-06012-20
M5-0.80 x 12
M5-0.80 x 16
M6-1.00 x 12
