Metric, cont.
Part No. Dimensions Type
Hex Nuts
M934-03-50 M3-0.50 Standard
M934-04-50
M934-04-B
M4-0.70
M4-0.70
Standard
Brass
M934-05-50 M5-0.80 Standard
M934-06-60
M934-06-64
M6923-06-80
M982-06-80
M6-1.00
M6-1.00
M6-1.00
M6-1.00
Standard
Std. (green)
Spiralock
Elastic Stop
M934-08-60
M6923-08-80
M982-08-80
M8-1.25
M8-1.25
M8-1.25
Standard
Spiralock
Elastic Stop
M934-10-60
M934-10-60F
M6923-10-80
M6923-10-62
M982-10-80
M10-1.50
M10-1.25
M10-1.50
M10-1.50
M10-1.50
Standard
Standard
Spiralock
Spiralock*
Elastic Stop
* This metric hex nut’s hardness is
grade 8.
M934-12-60
M934-12-60F
M6923-12-80
M982-12-80
M12-1.75
M12-1.25
M12-1.75
M12-1.75
Standard
Standard
Spiralock
Elastic Stop
M982-14-60 M14-2.00 Elastic Stop
M6923-16-80
M982-16-80
M16-2.00
M16-2.00
Spiralock
Elastic Stop
M934-18-80
M982-18-60
M18-2.5
M18-2.50
Standard
Elastic Stop
M934-20-80
M982-20-80
M20-2.50
M20-2.50
Standard
Elastic Stop
M934-22-60 M22-2.50 Standard
M934-24-80
M982-24-60
M24-3.00
M24-3.00
Standard
Elastic Stop
M934-30-80 M30-3.50 Standard
Washers
Part No. ID OD Thick
Bolt/
Screw
M125A-03-80
M125A-04-80
M125A-05-80
M125A-06-80
M125A-08-80
M125A-10-80
M125A-12-80
M125A-14-80
M125A-16-80
M125A-18-80
M125A-20-80
M125A-24-80
3.2
4.3
5.3
6.4
8.4
10.5
13.0
15.0
17.0
19.0
21.0
25.0
7.0
9.0
10.0
12.0
16.0
20.0
24.0
28.0
30.0
34.0
37.0
44.0
0.5
0.8
1.0
1.6
1.6
2.0
2.5
2.5
3.0
3.0
3.0
4.0
M3
M4
M5
M6
M8
M10
M12
M14
M16
M18
M20
M24
