KOLARC MX600 - MX600;MX500; MX400 Powersupply Front; Rear View

29
(1) On/Off Switch: To enable and disable the power supply.
(2) Water Unit Fuse Housing: 5 Amps
(3) Power Socket Fuse Holder: 2 Amps
(4) CO
2
gas heater socket (220V, 45Watt Maximum)
(5) Mains Cable Connection Female Jack (+)
(6) Female Jack (-)
(7) Interconnection Hose Socket
(8) Communication Fuse Slot: 10 Amps
(9) Robot Communication Bus Slot
MX600 / MX500
/ MX400
power supply
front/rear view
(1) (7)
(8)
(9)
(2)
(4)
(3)
(5)
(6)
2
2
3
3
4
4
5
5
6
6
A
B
C
D
