S300 Safety Guide | 2 English
2.3.3 Package Supplied
When you order a SERVOSTAR 300 series amplifier, you will receive:
S3xx
Mating connectors X0, X3, X4, X8
Mating Connector X9 (with SERVOSTAR 303-310 only ) (S3xx6)
S300 Safety Guide printed
All documentation in PDF format on CD-ROM
Setup software DRIVE.EXE on CD-ROM
The mating SubD connectors are not part of the package!
Accessories: (must be ordered separately; description see accessories manual)
Motor choke 3YL required for cable length above 25m
Motor cable and feedback cable
External brake resistor
Communications cable to the PC or Y-adapter for setting parameters of up to 6 servo amp-
lifiers from one PC
AC synchronous servomotor (linear or rotary), see specific motor manual
2.3.4 Ambient Conditions, Ventilation, and Mounting Position
Storage, hints (➜ # 38)
Transport, hints (➜ # 38)
Mains power supply
Aux. power supply
without brake and fan
with brake or fan
S30361, S30661, S31061:
1x110V-10% …1x230V+10%, 50/60 Hz
3x110V-10% …3x230V+10%, 50/60 Hz
S30101, S30301, S30601:
3x208V-10% ...3x 480V+10%, 50/60 Hz
20 V DC ... 30 V DC
24 V DC (-0% +15%),check voltage drop
Ambient temperature in
operation
0 to +40°C (32 to 104°F) at rated data
+40 to +55°C (113 to 131°F) with power derating 2.5% / K
Humidity in operation rel. humidity 85%, no condensation
Site altitude up to 1000m a.m.s.l. without restriction
1000 — 2500m a.m.s.l. with power derating 1.5%/100m
Pollution level Pollution level 2 to EN 60664-1
Vibrations Class 3M2 according to IEC 60721-3-3
Enclosure protection IP 20 according to EN60529
Mounting position generally vertical.
Ventilation
1A and 3A types
all other types
natural convection
built-on fan (optionally controlled, Ooption FN)
Make sure that there is sufficient forced ventilation within
the switchgear cabinet.
