2.3.5 Technical Data 110 / 230 V
SERVOSTAR 3xx61
Rated data DIM S30361 S30661 S31061
Rated supply voltage (grounded system)
V~ 1 x 110V
-10%
... 230V
+10%
, 50/60 Hz
V~ 3 x 110V
-10%
... 230V
+10%
, 50/60 Hz
Rated installed load for continuous operation @230V kVA 1.1 2.4 4
Rated DC bus link voltage V= 135...450
Rated output current (rms value, ± 3%)
@ 1x115V Arms 3.5* 8* 10*
@ 1x230V Arms 3* 6* 10*
@ 3x115V Arms 3.5 8 10
@ 3x230V Arms 3 6 10
Peak output current (max. ca. 5s, ± 3%)
@ 1x115V, 1x230V Arms 9* 15* 20*
@ 3x115V, 3x230V Arms 9 15 20
Clock frequency of the output stage kHz 8 /16 with 50% derating
Quiescent dissipation, output stage disabled W 12
Dissipation at rated current (incl. power
supply losses, without brake dissipation)
W 35 60 90
Brake circuit
- max. continuous power @230V kW 0.3 1 1
- external brake resistor Ohm 66 66 66
Overvoltage protection threshold V 235...455
Inputs/Outputs
Setpoint 1/2, resolution 14bit/12bit V ±10
- Common-mode voltage max. V ±10
Digital inputs - acc.to EN 61131-2 type 1, max. 30 VDC
Digital outputs, open emitter - max. 30 VDC, 10 mA
BTB/RTO output, relay contacts - max. 30 VDC, max. 42 VAC, 500 mA
Aux. power supply, electrically isolated without brake
V 20 - 30
A 1
Aux. power supply, electrically isolated with brake (con-
sider voltage loss!)
V 24 (-0% +15%)
A 2.5
Min./max. output current, brake A 0.15 / 1.5
Connections
Control signals — Mini-Combicon , 1.5mm²
Power signals — Classic Combicon 2.5mm²
Feedback input — SubD (female)
PC interface, CAN, Encoder emulation, ROD/SSI — SubD (male)
Mechanical
Weight kg 2.7
Height without connectors mm 275 279
Width mm 70
Width without/with connectors mm 171 / <230
*in single-phase applications nom./peak current is limited to value below nominal value.
More technical data see Instructions Manual.
