Kollmorgen SERVOSTAR 300 Safety Guide

2.3.7 Fusing
Internal Fusing
Circuit internal fuse
Auxiliary supply 24V 3.15 A
Brake resistor electronic
External fusing
Fusible cutouts or similar S30361/ S30101/ S30301 S30661/ S31061/ S30601
AC supply F
N1/2/3
6 A 10 A
24V supply F
H1/2/
max. 8 A
Brake resistor F
B1/2
6 A 6 A
2.3.8 Recommended Tightening Torques
Connector Recommended torque
X0, X8, X9 0.5 to 0.6 Nm (4.43 to 5.31 in lbf)
Ground bolt 3.5 Nm (31 in lbf)
S300 Safety Guide | 2 English
Kollmorgen | wiki-kollmorgen.eu | December 2015 45
