2.3.6 Technical Data 230V ... 480 V
SERVOSTAR 3xx01
Rated data DIM S30101 S30301 S30601
Rated supply voltage (grounded system) V~ 3 x 208V
-10%
... 480V
+10%
, 50/60 Hz
Rated installed load for continuous operation @480V kVA 1.2 2.5 5
Rated DC bus link voltage V= 260...900
Rated output current (rms value, ± 3%)
@ 3x230V Arms 2 5 6
@ 3x400V Arms 1.5 4 6
@ 3x480V Arms 1.5 3 6
Peak output current (max. ca. 5s, ± 3%)
@ 3x208V...3x480V Arms 4.5 7.5 12
Clock frequency of the output stage kHz 8 /16 with 50% derating
Quiescent dissipation, output stage disabled W 12
Dissipation at rated current (incl. power
supply losses, without brake dissipation)
W 40 40 90
Brake circuit
- max. continuous power @480V kW 0.3 1 1
- external brake resistor Ohm 91 91 91
Overvoltage protection threshold V 455...900
Inputs/Outputs
Setpoint 1/2, resolution 14bit/12bit V ±10
- Common-mode voltage max. V ±10
Digital inputs - acc.to EN 61131-2 type 1, max. 30 VDC
Digital outputs, open emitter - max. 30 VDC, 10 mA
BTB/RTO output, relay contacts - max. 30 VDC, max. 42 VAC, 500 mA
Aux. power supply, electrically isolated without brake
V 20 - 30
A 1
Aux. power supply, electrically isolated with brake (con-
sider voltage loss!)
V 24 (-0% +15%)
A 2,5
Min./max. output current, brake. A 0.15 / 1.5
Connections
Control signals — Mini-Combicon , 1.5mm²
Power signals — Power Combicon 4mm²
Feedback input — SubD (female)
PC interface, CAN, Encoder emulation, ROD/SSI — SubD (male)
Mechanical
Weight kg 2.7
Height without connectors mm 275 279
Width mm 70
Width without/with connectors mm 171 / <230
More technical data see Instructions Manual.
