M-SS-017-07 Rev C 16 SERVOSTAR CD
BUS MODULE ELECTRICAL SPECIFICATIONS
NOTE
NOT USED FOR SERIES 5.
Product Model PA-LM
Logic Input Power Voltage (AC) Nom. ?10%
110 to 120
Max. Current 1? (A)
1
Line Frequency 47-63
Internal Fuse (amps) (internal) 2.5
+8 VDC Supply Voltage (VDC) +7.25 to +8.5
+8 VDC Supply Current (amps) 2.2
15 V Supply Voltage (±VDC) 14.25 to 16
15 V Supply Current (amps) 0.8
Internal Fuses (amps) (?15V/+8 V)
1.5/3.5
Logic Output
Power (Source)
Max. # of Drives Sourced Refer to Bus Module Sizing Application Note
Internal heat dissipation 7
Operation temperature (?C/?F)
5/41 to 45/113
Storage temperature (?C/?F)
0/32 to 70/158
Ambient humidity (%) 10 to 90
Atmosphere without corrosive gasses or dust
Altitude Derate 5% per 1000 ft. above 3300 ft.
Environment
Vibration (g) 0.5
REGEN INFORMATION
Product Model Cx03 Cx06 Cx10
Peak current (amps) 20
Minimum resistance (ohms) 20
External Shunt Regulator
watts 200
Capacitance (Farads) 0.00082 0.00164
BUS Voltage (nominal) (VDC) 325
V
HYS
(Regen circuit turn-off) (VDC) 370
Application Information
V
MAX
(Regen circuit turn-on) (VDC) 390
External Regen Kits
ERH-26
? ? ?
*See the SERVOSTAR
®
S/CD-Series Regeneration Requirements Application Note on the PSP CD-
ROM for guidance on application sizing of Regen Kits.
