M-SS-017-07 Rev C 24 SERVOSTAR CD
NO MESSAGE FAULTS
Display Fault Description Fatal Non-Fatal Flashing Display Steady Display
?
Watchdog (DSP)
?
Watchdog (HPC)
-1 No Compensation
-2 Invalid Velocity Control
-3 Encoder not Initialized on attempt to enable
-4 Encoder Initialization failure
-5 AutoConfig failure
L 1 Hardware CW limit switch open
L 2 Hardware CCW limit switch open
L 3 Hardware CW and CCW limit switches
open
L 4 Software CW limit switch is tripped
(PFB>PMAX & PLIM=2)
L 5 Software CCW limit switch is tripped
(PFB<PMIN & PLIM=2)
A 3 Positive and negative analog supply fail
I RAM failure (during init)
c EPROM checksum (during init)
E101 Altera load failure (during init)
E102 Altera DPRAM failure (during init)
E103 DSP load fail (during init)
E104 DSP alive failure (during init)
8 Test LED
B Indexed position with zero velocity
