28 PC800, 850-8
SEN00384-02 10 Structure, function and maintenance standard
Center swivel joint
Unit: mm
1. Cover
2. Body
3. Slipper seal
4. Oil seal
5. Shaft
No. Check item Criteria Remedy
6
Clearance between rotor and
shaft
Standard size Standard clearance Clearance limit
Replace
110 0.056 – 0.105 0.111
