Komatsu Galeo PC800-8 User Manual

6 PC800, 850-8
SEN00793-02 40 Troubleshooting
E-1 Engine does not start (Engine does not rotate)
Failure
phenomenon
• The engine does not start. (Engine does not rotate)
Relative
information
• The engine starting circuit is equipped with the start lock mechanism of lock lever type.
Possible causes
and standard
value in normal
state
Cause Standard value in normalcy and references for troubleshooting
1
Battery capacity
insufficient
aTurn the engine starting switch OFF for the preparations, and hold it in
the OFF position during the troubleshooting.
Battery voltage Electrolyte specific gravity
Min. 24 V Min. 1.26
2
Defective circuit breakers
No. 1 or 6 or fuse 3 or 20
If a circuit breaker is turned OFF or a fuse is broken, the circuit probably
has grounding fault (See cause 9).
3
Defective starting switch
(Internal disconnection)
aTurn the engine starting switch OFF for the preparations, and hold it in
the ON position and start the engine during the troubleshooting.
H06 (male) Starting switch Resistance
Between (1) – (4)
OFF Min. 1 Mz
ON Max. 1 z
4
Defective lock switch
(Internal short-circuiting)
aTurn the engine starting switch OFF for the preparations, and hold it in
the OFF position during the troubleshooting.
S14 (female) Lock lever Resistance
Between (1) – (3)
FREE Min. 1 Mz
LOCK Max. 1 z
5
Defective starting motor
cut-out relay
(Internal defect)
aTurn the engine starting switch OFF for the preparations, and hold it in
the OFF position during the troubleshooting.
R06 (male), R07 (male) Resistance
Between (1) – (2) 100 – 500 z
Between (3) – (5) Min. 1 Mz
Between (3) – (6) Max. 1 z
6
Defective starting motor
(Internal defect)
aTurn the engine starting switch OFF for the preparations (with the wir-
ing harness connected), and start the engine for troubleshooting.
Starting motor Voltage
Between B – chassis
ground
B (Power
supply)
20 – 30 V
Between ST (1) –
chassis ground
S (Start) 20 – 30 V
Between ST (2) –
chassis ground
R
(Charge)
Max. 12 V
If the above voltages are normal and the starting motor does not rotate,
the starting motor has a defect in it or the engine is defective.
7
Defective alternator (Inter-
nal short-circuiting)
aTurn the engine starting switch OFF for the preparations (with only
wiring harness R disconnected), and hold it in the ON position during
the troubleshooting.
Alternator Voltage
Between terminal R –
chassis ground
Max. 12 V
