KT-70E / KT-90E / KT-70SE User Manual Page 56 of 59 24 April 2018
A
Qty
Overview
Part Number
001
1
Crankcase
910010
002
4
Screws
910020
004
1
Oil drain plug
910040
004a
1
Copper seal
910041
005
1
Oil tube holder
910050
005
1
Gasket
910051
006
1
O-ring
910061
007
2
Bearing cover
910070
007a
8
Screws
008
2
O-rings for bearing cover
910080
009
2
Crankshaft seals
910090
010
2
Crankshaft ball bearings
910100
B
Crankshaft with piston rod
011
1
Crank arm (drive side) with
Crank axle
910110
012
1
Crank arm (fan side)
910120
014
2
Dowel pins
910140
015
4
Spacers (0.3 - 0.5mm thickness)
910150
016
3
Roller bearings
910160
017
1
Piston rod - 1st stage
910170
018
2
Piston rods - 2nd & 3rd stages
910180
C
1st Compressor stage
019
1
Piston - 1st stage
910190
020
1
Piston pin
910200
021
2
Piston pin snap ring
910210
022
1
Gasket with O-ring
910220
023
1
Wiper ring with O-ring
910230
024
1
Cylinder
910240
025
1
Cylinder housing O-ring
910250
027
1
Cylinder cover
910270
027a
4
Cylinder head bolts
910490
028
1
Vent connection
910280
029
1
Threaded elbow joint
910290
032
1
Valve seat
910320
033
1
Cylinder - cylinder head O-ring
910330
034
1
Valve seat O-ring
910340
035
1
Intake valve
910350
036
1
Exhaust valve
910360
037
1
Exhaust valve spring
910370
D
2nd Compressor stage
038
1
Piston - 2nd stage
910380
039
1
Piston pin
910390
040
1
Piston pin snap ring
910400
041
1
Gasket with O-ring
910410
042
1
Cylinder
910420
044
1
Housing - cylinder head O-ring
910440
045
1
Cylinder cover
910450
046
1
Intake threaded elbow joint
910460
047
1
Wiper ring with O-ring
910470
048
1
Exhaust threaded elbow joint
910290
049
4
Cylinder head bolts
910490
050
1
Valve seat
910500
051
1
Intake valve
910510
052
1
Intake valve spring
910520
053
1
Exhaust valve
910530
054
1
Exhaust valve spring
910540
055
1
Cylinder - cylinder head O-ring
910550
056
1
Cylinder - valve seat O-ring
910560
E
3rd Compressor stage
057
1
Piston - 3rd stage
910570
