KT-70E / KT-90E / KT-70SE User Manual Page 57 of 59 24 April 2018
058
1
Piston pin
910580
059
1
Piston pin snap ring
910400
060
1
Gasket with O-ring
910600
061
1
Cylinder
910610
063
1
Housing - cylinder head O-ring
910440
064
1
Cylinder cover
910640
065
1
Wiper ring with O-ring
910650
066
1
Intake threaded elbow joint
910460
067
1
Exhaust threaded elbow joint
910670
068
4
Cylinder head bolts
910490
069
1
Valve seat
910690
070
1
Intake valve
910700
071
1
Intake valve spring
910710
072
1
Exhaust valve
910720
073
1
Exhaust valve spring
910730
074
1
Cylinder - cylinder head O-ring
910740
075
1
Cylinder - valve seat O-ring
910750
F
Oil filler tube and housing
pressure equalization
077
1
Oil filler neck
910760
078
1
Connector, straight
910780
079
1
Ventilation tubing
910790
080
1
dipstick
910800
081
1
Rubber ring
910810
G
Intercooler and aftercooler
Safety valves
082
1
Intercooler 1st to 2nd stage
910820
083
1
Intercooler 2nd to 3rd stage
910830
084
1
Aftercooler 3rd stage
910840
085
1
Safety valve 1st stage 10-16 bar
910850
086
1
condensate separator
910860
087
3
Connector, angle
910870
090
1
Safety valve 2nd stage 30-60bar
910900
091
1
Threaded elbow joint
910910
092
1
Connecting pipe Filter
910920
Engine and cooling fan. See
figure B
095
1
Flywheel disk
910950
096
1
Allen stud screw
910960
097
1
Adjustment spring
910970
098
1
Flange disk
910980
099
1
Set screw
910990
100
1
Cooling fan
911000
101
1
Adapter cooling fan
911010
102
1
Adjustment spring
911020
104
1
Sink bolt
911040
105
3
Hex screws
911050
H
Casing
106
1
Cover fan
107
1
Cover pulley
108
1
Side panel filter
109
2
Hose clamps
110
1
Baseplate
111
4
feet
112
4
Spacer tube
113
4
Nuts M6 x 10
113a
4
Washer
114
8
Screw M6 x 10
115
1
stiffening profile
116
1
handle
117
1
Side panel motor
118
1
Cover motor
119
4
Screw M8 x 80
119a
4
Washer
120
13
Screw M5 x 10
